Digital Vision Network
5000 Rackmount Series
Installation Guide
September, 2011
24-10129-4 Revision G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVN 5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Johnson Controls DVN 5000 Series

Summary of Contents for Johnson Controls DVN 5000 Series

  • Page 1 Digital Vision Network 5000 Rackmount Series Installation Guide September, 2011 24-10129-4 Revision G...

  • Page 2: Federal Communication Commission Notice

    All Rights Reserved (805) 522-5555 www.johnsoncontrols.com No part of this document may be reproduced without the prior permission of Johnson Controls, Inc. These instructions are supplemental. Often they are supplemental to other manufacturer’s documentation. Never discard other manufacturer’s documentation. Publications from Johnson Controls, Inc.
  • Page 3 Boot disk failure recovery (see page 40)  Quick start checklist (see page 41)  ACKAGE ONTENTS Thank you for choosing the Johnson Controls DVN 5000 Series server. DVN 5000 SERIES USB FLASH DRIVE: SERVER TRAINING DVD • Client Software •...

  • Page 4: Manual Conventions

    (menu option 5) in the USA, or one of the following numbers for Europe: +49 20 12 40 04 50  +33 6 72 99 49 66  24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 5: Installation Information

    SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT. MPORTANT NSTALLATION NFORMATION Environmental Conditions The DVN 5000 Series server should be stored and/or installed in an environment that conforms to the following specifications: Item Specification Operating Temperature 41 to 95F (5 to 35C) Storage Temperature 14...
  • Page 6 4. Press each drive into its designated slot until it clicks and the handle is held behind the release button. (front view) 0 1 2 3 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 7: Connecting The Power

    Replace the cord with same type and ratings. Contact with components carrying hazardous voltage can cause electric shock and may result in severe personal injury or death. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 8: Switching The Server On And Off

    DVN 5000 Rackmount Series Server Switching the Server On and Off All models of the DVN 5000 Series servers are equipped with a main power switch located at the back of the server that turns the power on and off.

  • Page 9: Voltage Selection

    DVN 5000 Series Software Installation and Configuration Manual. Voltage Selection The DVN 5000 series server does not have a voltage selection switch. The rating is 100-240 VAC, 50/60 Hz. Verify that this voltage type and range matches the local power supply value.

  • Page 10: Lithium Battery Replacement

    6. Replace the components you have removed and the top server panel. The DVN can now be switched back on. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 11: Servicing And Repair

    DVN model, manufacturing date code, country where the unit was assembled, and a warning statement. This sticker must be affixed to the unit and intact to receive warranty service on a defective DVN unit at a Johnson Controls authorized repair facility.
  • Page 12 The DVN 5000 already comes equipped with internal EOL termination functionality. (This note does not apply to DVN 5000X Real-Time models). 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 13 DVN 5000 Rackmount Series Server Installation Guide DVN 5000 Real-Time or Multiplexed Connections 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 14 Installation Guide DVN 5000 Rackmount Series Server DVN 5000X Real-Time (for Network Cameras) Connections 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 15: Alarm Inputs

    Not Used Ground Alarm16 Alarm15 Alarm14 Input Example N/O shown (may also be N/C, depending on the software configuration) Customer Supplied Ground 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 16: Auxiliary Outputs

    (N/O) relay contacts. When the contact is activated, there is a contact closure to ground. The relay contacts are rated 250mA at 24 VAC or DC. For information on configuring the auxiliary output to be normally closed (N/C), refer to the DVN 5000 Series Software Installation and Configuration Manual. Output13 Output12...

  • Page 17: Output Example

    DVN 5000 model. DVN Model Mono Channels Stereo Channels DVN5004-RT DVN5008-RT DVN5016-RT DVN5016X DVN5016R DVN5016M DVN5008R DVN5008M DVN5032X DVN5032R DVN5032M 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 18: Audio Specifications

    DVN 5000 does not supply power to a condenser microphone). Enable a microphone in the DVN software as the left channel for each audio input. Refer to the DVN 5000 Series Software Installation and Configuration Manual for assistance. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc.

  • Page 19: Setup Outline

    ERVER ETUP UTLINE For detailed information on how to perform each step, refer to the DVN 5000 Series Software Installation and Configuration Manual.  To power on the server: 1. Verify that the power switch on the back of the unit is switched on.
  • Page 20 Setting” on page 32 for more information. 4. Click the Login button to log into the server. When you configure your DVN 5000 Series server for the first time, the default password will remain undefined until you specify it. For security reasons, we highly recommend that you add the administrator’s password...

  • Page 21: To Configure Network Settings

    Setup. 2. On the Setup screen, click System. 3. On the System Configuration screen, click Network Cards next to Incoming Connections. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 22 DVN 5000 Series Software Installation and Configuration Manual. Local Area Connection Local Area Connection 2 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 23: To Set The Date And Time

    To manually set the DVN 5000 server’s clock, set the hour, date, and time zone and click Submit. You will be logged out. 3. When the following message appears, click OK. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 24 Video window. 5. Enter the preferred camera name in the Camera drop-down list. 6. Click the Apply button 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 25 The selected encoder setting determines the values in the Encoder Type, Encoder Resolution, and Encoder Rate fields. Refer to the DVN 5000 Series Software Installation and Configuration Manual for more information on configuring cameras.  To configure network cameras: Network cameras are only supported on DVN 5000 servers running software Version 2.7 or higher.
  • Page 26 The DVN server and all the available video channels appear. Select the video channel you wish to use as the source for the selected DVN server and click Done. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 27 15. Repeat the previous steps for each network camera you wish to configure.  To configure storage: 1. On the Setup screen, click Storage. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 28  Storage group disks/nodes  Sectors  For detailed procedures, refer to the DVN 5000 Series Software Installation and Configuration Manual. 1. On the RemoteControl Main screen, click Setup. 2. On the Setup screen, click Scheduler. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc.
  • Page 29 (24 hours). As an alternative, you can grant the user access for limited or multiple time intervals. Refer to the DVN 5000 Series Software Installation and Configuration Manual for details. 4. Use the Camera drop-down list to select the camera whose sector(s) you want to configure.
  • Page 30 Cameras Configuration screen (Standard tab). 5. Click Apply. 6. On the Record Scheduler screen, click OK. 7. On the Setup screen, click OK. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 31 1. On the Setup screen, click Users. 2. On the Users Configuration screen, select the admin icon and click Edit. 3. Edit the password and click OK. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 32  To add users: 1. On the Setup screen, click Users. 2. On the Users Configuration screen, click Add. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 33 4. Specify the user name, password, and other settings as required and click The OK button 5. On the Users Profile page, click to save your changes. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 34 1. Export the DVN 5000 system configuration settings. Refer to the DVN 5000 Software Installation and Configuration Manual. 2. On the Setup>System Configuration screen, click the Clear and Shutdown button. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 35 RITICAL OR FFLINE LARMS Johnson Controls recommends enabling the DVN Internal RAID is Critical and DVN Internal RAID is Offline alarms so that you are notified and can take corrective action in the event the RAID status changes.  To enable the DVN Internal RAID is Critical and DVN Internal RAID is Offline: 1.
  • Page 36 For information on creating and managing time intervals, refer to the DVN 5000 Software Installation and Configuration Manual. 11. Click the Apply button to save your changes. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 37: Troubleshooting

    DVN 5000 Rackmount Series Server Installation Guide For more information on alarm configuration, refer to the DVN 5000 Series Software Installation and Configuration Manual. ROUBLESHOOTING Troubleshoot any issues you are experiencing with your DVN 5000 according to the following table.
  • Page 38 "Disconnected..." video screen. To reset the DVN’s video format, see “Changing the Server’s Video Standard Setting” on page 32. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 39 RAID drives are properly inserted and latched in the drive bay. Contact your nearest district sales/service office for technical  assistance. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 40  select PTZ Camera as the Device Type. Verify you have selected the correct manufacturer from the Device Class drop-down list. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 41 (disabled), exit the current menu and retry. Another user may be currently accessing the menu. Only one  user can access a category at any one time. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
  • Page 42 8. Install the rest of the drives and/or disks you previously unplugged. 9. Restart the DVN again and verify proper operation. 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.

  • Page 43: Hardware Installation Checklist

    Rackmount Series server. The checklist provides only the essential steps required to get the DVN 5000 up and running. Detailed configuration instructions and additional features are covered elsewhere in this document and in the DVN 5000 Series Software Installation and Configuration Manual.
  • Page 44  Configure the unit’s network settings. (Setup>System Configuration>Network Cards)  Configure any network cameras. (Setup>Cameras Configuration>Network tab)  Verify storage drive is configured and recording. (Setup>Storage) 24-10129-4 Rev. G This document contains confidential and proprietary information of Johnson Controls, Inc. © 2011 Johnson Controls, Inc.
