Panel removal

1) Switch off the power supply to the panel!
2) Insert a flat-head screwdriver through the openings in the terminal cover (Fig. 4) and
lift up the latches holding the panel.
3) Proceed in reverse order to the steps followed during installation.
Type of panel
Ecosun S+ 18
Ecosun S+ 24
* the recommended minimum distance in order to limit the warming of the wall
is 1000 mm
Frame dimensions
(with edging)
l x w x h
[mm]
1596 x 298 x 100
1596 x 298 x 100
Dimensions of the
opening
l x w x h*
[mm]
1570 x 260 x 400
1570 x 260 x 400
Total weight Min. volume of
(panel + false ceiling for
frame) panel unit
[kg]
16,5
16,5
[m3]
3,7
3,7
