Operating Instructions
2. Function
The SolidFlow 2.0 is a measuring system which has been specially developed for measuring the quantity
•
of solids conveyed in pipelines.
The sensor works with the latest microwave technology. It is only used in metallic pipelines. The special
•
integration of microwave technology together with the metallic pipeline creates a homogeneous
measurement field.
The microwave radiation in the pipeline is reflected by the solid particles and received by the sensor.
•
The frequency and amplitude of the received signals are analysed.
The frequency-selected evaluation system ensures that only moving particles are measured and
•
deposits are suppressed.
SolidFlow 2.0 features active stratification compensation which increases measurement accuracy.
•
Fig. 5: Integration and reflection of microwaves
5
