- Page 1 { Design. Uniqueness. Innovations } { Design. Uniqueness. Innovations } SQ-07MT HD Technical support 7” video intercom with touch screen Manual download User manual Thank you for choosing our equipment...
-
Page 2: Table Of Contents
This manual can contain some inaccuracy or misprint. The owner reserves the right to make corrections to the information described in the user manual and device package. 3. Description..................................... The last revision of this manual is available on www.slinex.com 4. Installation....................................4.1 Cable requirements.............................. -
Page 3: Package
SQ-07MT HD 1. Package 3. Description SQ-07MT HD door monitor − 1 pc. Wall mounting bracket − 1 pc. Connection wires − 7 pcs. Mounting screws and anchors − 1 pkg. User manual − 1 pc. 2. Speci cation 20 mm (0.78") 197 mm (7.75") -
Page 4: Cable Requirements
4.2 Schematic diagrams 4.1 Cable requirements Diagram 1. SQ-07MT HD outdoor panels, cameras and locks connection. Disconnect all power cables before device installation. This device can be connected with such cable types depends on the distance between door monitor and... -
Page 5: Unit Mount
SQ-07MT HD Notes: Diagram 2. SQ-07MT HD system connection. Use «Power» plug to connect external power supply +13,5 V. While use external power supply please keep main power cord ~100-240 V disconnected from the outlet, otherwise it can damage monitor circuits. -
Page 6: Operation
SQ-07MT HD 5.2 Outdoor panel and camera image view 5. Operation 5.1 Incoming call Standby mode Standby mode Monitor will display Press «Monitor» the image from the button on the rst outdoor panel monitor Visitor presses call button Visitor presses call button (monitoring time –... -
Page 7: Intercom
SQ-07MT HD Notes: 5.4 Intercom 1) If only one outdoor panel connected to the monitor then you can escape monitoring mode by pressing Two monitors connected into one system are used. «Monitor» button one more time. (all other sources of video signal should be disabled in the monitor settings). -
Page 8: System Settings
SQ-07MT HD 6.2 System settings Press «System» icon in the main menu to enter system settings of the monitor: Settings Language English Monitor System Ring Mode Date & Time Video settings Main menu Main menu Screen saver Disabled Exit SD card info... -
Page 9: Ring And Volume Settings
SQ-07MT HD Time setting Settings Language English Main menu Date & Time Main menu Video settings 2018 / 09 / 20 15 : 33 : 48 Screen saver Disabled SD card info Format System SD card capacity System 1.8 GB... -
Page 10: Working Mode Settings
SQ-07MT HD Door 1 unlock time − Door 1 relay delay time, 1,3, 5, 7 or 9 seconds; Ring settings Door 2 unlock time − Door 2 relay delay time, 1,3, 5, 7 or 9 seconds; Key backlight − «On» or «O »;... - Page 11 SQ-07MT HD MD setting CAM1 alarm time − alarm melody ringing time, activated by CAM1 motion sensor, from 00 to 40 MD source CAM1 seconds; MD sensitivity Middle CAM2 alarm time − alarm melody ringing time, activated by CAM2 motion sensor, from 00 to 40...
-
Page 12: Custom Image Viewing (Photo Frame)
SQ-07MT HD Press on le name to start playback. Use the keys on the bottom of the image to pause playback or delete 6.9 Custom image viewing (photo frame) current record. Also you can return to the le list by pressing button. -
Page 13: Manual And Automatic Recording
SQ-07MT HD 8. Manual and automatic recording 10. Limited warranty User can take manual snapshots or record video during monitoring outdoor panel or CCTV camera. Manufacturer guarantees product normal functioning during the warranty period if the user keeps all Press icon on the right side of the monitoring screen to start manual recording then press safety instructions described in that manual.
