- Page 1 Design. Uniqueness. Innovations Design. Uniqueness. Innovations SM-07MN 7” video intercom Technical support User manual Thank you for choosing our equipment...
-
Page 2: Table Of Contents
This manual can contain some inaccuracy or misprint. The owner reserves the right to make corrections to the information described in the user manual and device package. 3. Description..................................... The last revision of this manual is available on www.slinex.com 4. Installation....................................4.1. Cable requirements............................. -
Page 3: Package
SM-07MN 3. Description 1. Package SM-07MN door monitor − 1 pc. Wall mounting bracket − 1 pc. Connection wires − 1 pkg. Mounting screws and anchors − 1 pkg. User manual − 1 pc. 2. Speci cation 193 mm Display Microphone «Intercom»... -
Page 4: Cable Requirements
4.2. Schematic diagrams 4.1. Cable requirements Diagram 1. SM-07MN outdoor panels, cameras and locks connection. Disconnect all power cables before device installation. able type that is used for device connection depends on the distance between the last indoor monitor in... -
Page 5: Unit Mount
SM-07MN 4.3. Unit mount Diagram 2. SM-07MN system connection. 1) Take the surface mount bracket from the kit and place it 150-160 cm from the oor line; 2) Mark and drill four halls in the wall; 3) Take four nuts from the kit and hammer them into the drilled halls;... -
Page 6: Operation
SM-07MN 5. Operation 5.2. Door panel and camera image view 5.1. Incoming call Standby mode Standby mode Monitor will display Press «Monitor» the image from the button on the rst door panel Visitor presses call button Visitor presses call button monitor (monitoring time –... -
Page 7: Incoming Call Redirection
SM-07MN Notes: 5.4. Intercom 1) If several monitors are connected into one system, user can view the image from the door panels and Two monitors connected into one system are used. cameras on any monitor inside this system. The image will be transferred from the «Master» monitor outdoor panels and cameras to the «Slave»... -
Page 8: Main Menu
SM-07MN Release date − date of software release; 6.1. Main menu Format SD − micro SD card formatting. Please format microSD card before use it. Recommended to use microSD cards of the 6-th class and above; Format flash − internal memory formatting;... -
Page 9: Ring Settings
SM-07MN Main menu Software version: 3.1.0.1 Main menu Release date: 2020-05-28 Door 1 Door 2 Format SD Format flash Backup pictures Ring System Outdoor panel melody: Update Reboot Ring select Information 6.3. Ring settings Press «Ring» icon in the main menu to enter melody and volume settings. -
Page 10: Alarm Settings
SM-07MN Record mode: «Snapshot» – take snapshot while incoming call or manually; Ring time − alarm ringing time trigerred by CAM1 or CAM 2 motion sensor, from 00 to 30 seconds; «Record» – record video while incoming call or manually;... -
Page 11: Image Parameter Settings
SM-07MN Software motion detector can observe and detect motion without any external sensors using any camera image changes with the time. Camera power that is used for motion detection should be constantly on to let the monitor observe image changes and detect it. - Page 12 SM-07MN Every video source has its own image settings: Press «Record files» or «Snapshot files» icon to enter snapshots or records playback menu then choose the Brightness – parameter range from 0 to 50, 25 used by default; le to play by moving joystick up or down.
-
Page 13: Limited Warranty
SM-07MN 7. Manual and automatic recording 9. Limited warranty User can take manual snapshots or record video during monitoring outdoor panel or CCTV camera. Manufacturer guarantees product normal functioning during the warranty period if the user keeps all Press joystick on the right side of the monitor to start manual recording then press joystick safety instructions described in that manual.
