- Page 1 Design. Uniqueness. Innovations Design. Uniqueness. Innovations SQ-07MTHD 7" video intercom with touch screen Technical support User manual Thank you for choosing our equipment...
-
Page 2: Table Of Contents
This manual can contain some inaccuracy or misprint. The owner reserves the right to 3. Description..................................... make corrections to the information described in the user manual and device package. 4. Installation....................................The last revision of this manual is available on www.slinex.com 4.1. Cable requirements............................. Safety instructions 4.2. Schematic diagrams............................ -
Page 3: Package
SQ-07MTHD 1. Package 3. Description SQ-07MTHD indoor monitor − 1 pc. Wall mounting bracket − 1 pc. Connection wires − 7 pcs. Mounting screws and anchors − 1 pkg. User manual − 1 pc. 2. Specification 20 mm (0.78") 197 mm (7.75") -
Page 4: Cable Requirements
4. Installation 4.2. Schematic diagrams 4.1. Cable requirements Diagram 1. SQ-07MTHD outdoor panels, cameras and locks connection. Disconnect all power cables before device installation. This device can be connected with such cable types depends on the distance between door monitor and door panel: а) Use 4-wire cable with such parameters:... -
Page 5: Unit Mount
SQ-07MTHD Notes: Diagram 2. SQ-07MTHD system connection. Use «Power» plug to connect external power supply +13,5 V. While use external power supply please keep main power cord ~100-240 V disconnected from the outlet, otherwise it can damage monitor circuits. ** Outdoor panels, cameras, power supplys, locks and motion sensors illustrated on the schemes are optional devices and aren’t included into monitors kit. -
Page 6: Operation
SQ-07MTHD 5.2. Outdoor panel and camera image view 5. Operation 5.1. Incoming call Standby mode Standby mode Monitor will display Press «Monitor» the image from the button on the first outdoor panel monitor Visitor presses call button Visitor presses call button (monitoring time –... -
Page 7: Incoming Call Redirection
SQ-07MTHD Notes: 5.4. Intercom 1) If only one outdoor panel connected to the monitor then you can escape monitoring mode by pressing Two monitors connected into one system are used. «Monitor» button one more time. (all other sources of video signal should be disabled in the monitor settings). -
Page 8: System Settings
SQ-07MTHD 7. Settings 28 . 12 . 2020 13 : 48 7.1. System settings System Home screen System Language English Main Ring Time 20.09.2019 14:02 Main menu Door 1 Door 2 CAM1 CAM2 menu Video Screen saver 3 min. Memory... - Page 9 SQ-07MTHD 7.3. Video settings 7.2. Ring settings Video Home screen Ring Home screen System Door 1 1080P Main System Ring Door 1 melody Ring 01 Door 2 CVBS 720P NTSC menu Main Ring Video Door 2 melody Ring 05 CAM1...
-
Page 10: Software Motion Detection Settings
SQ-07MTHD 7.4. Memory settings Main Motion detection Home screen menu Memory Home screen System Software motion detection System SD card capacity 7.33 GB Ring Source Door 1 Settings Main Ring Video menu Sensitivity Middle Video Free 7.33 GB Memory Action... - Page 11 SQ-07MTHD Area − motion detection area setting defines the part of the image in which motion detection Hardware motion detection can detect motion by means of external device (hardware motion sensor). performed; There are two types of sensors that can be connected to the monitor: sensor with normally opened contacts (NO) and sensor with normally closed contacts (NC).
- Page 12 SQ-07MTHD 7.7. Photo frame settings 7.9. Factory reset Photo frame Home screen Factory reset Home screen System Enable photo frame System Main Main menu Ring menu Working time 1 min. Warning! Ring All parameters will be reseted to the factory defaults...
- Page 13 SQ-07MTHD 8.1. Video playback 8.3. Custom MP3 ringtone Press «Files» icon in the main menu then press «Video» folder icon. Create «RING» folder in the root of microSD card, if it isn’t already created by the monitor. Paste MP3 files you would like to use as a ringtone into this folder.
-
Page 14: Limited Warranty
SQ-07MTHD 10. Limited warranty Manufacturer guarantees product normal functioning during the warranty period if the user keeps all safety instructions described in that manual. Warranty period is 12 months from the moment of the product purchasing (warranty period could be extended up to 24 months or more, depending on the local regulations).
