- Page 1 SQ-07MT UNIQUE 7” video door phone DIRECT with touch screen User manual Thank you for the choice of our equipment { Design. Uniqueness. Innovation }...
-
Page 2: Table Of Contents
This manual can contain some inaccuracy or misprint. The owner reserves the right to 3. Description...................................... 4 make corrections to the information described in the user manual and device package. 4. Installation....................................... 5 The last revision of this manual is available on www.slinex.com 4.1 Cable requirements............................... 5 Safety instructions 4.2 Schematic diagrams..............................6 Read and keep that manual. -
Page 3: Design. Uniqueness. Innovation
UNIQUE { Design. Uniqueness. Innovation } DIRECT 3. Description 1. Package SQ-07MT door monitor − 1 pc. Wall mounting bracket − 1 pc. Connection wires − 7 pcs. Mounting screws and nuts − 1 pkg. User manual − 1 pc. -
Page 4: Cable Requirements
DIRECT 4. Installation 4.2 Schematic diagrams Diagram 1. SQ-07MT door panels, cameras, locks and TV connection. 4.1 Cable requirements Disconnect all power cables before device installation. This device can be connected with such cable types depends on the distance between door monitor and... -
Page 5: Unit Mount
{ Design. Uniqueness. Innovation } DIRECT 4.3 Unit mount Diagram 2. SQ-07MT system connection. 1) Take the surface mount bracket from the kit and situate it 150-160 cm from the oor line. 2) Mark and drill four halls in the wall. -
Page 6: Operation
UNIQUE { Design. Uniqueness. Innovation } DIRECT 5. Operation 5.2 Door panel and camera monitoring 5.1 Incoming call Standby mode Standby mode Monitor will display Press «Monitor» the image from the button or slide from rst door panel left to right side of Visitor presses call button Visitor presses call button (monitoring time –... -
Page 7: Intercom
UNIQUE { Design. Uniqueness. Innovation } DIRECT Notes: 5.4 Intercom 1) If only one door panel connected to the monitor then you can exit monitoring mode by pressing Two monitors connected into one system are used. «Monitor» button one more time. (all other sources of video signal should be disabled in the monitor settings). -
Page 8: System Settings
UNIQUE { Design. Uniqueness. Innovation } DIRECT Release date − date of software release. Format SD − micro SD card formatting. Please format microSD card before use it. Recommended to use microSD cards of the 6-th class and above. Format flash − internal memory formatting. Backup pictures−... -
Page 9: Melody And Volume Settings
UNIQUE { Design. Uniqueness. Innovation } DIRECT Main menu Software version: 1.1.3.2 Main menu Release date: 2016-07-08 Door 1 Format SD Format flash Door 2 Ring Backup pictures System Update Reboot Ring select Information 6.3 Melody and volume settings Press «Ring» icon in the main menu to enter melody and volume settings. Following parameters are available in the «Ring»... -
Page 10: Alarm Settings
UNIQUE { Design. Uniqueness. Innovation } DIRECT CAM1 − «On» or «O », include or exclude first CCTV camera from the monitoring list. Record mode: «Snapshot» – take snapshot while incoming call or manually; CAM2 − «On» or «O », include or exclude second CCTV camera from the monitoring list. «Record»... -
Page 11: Display Settings
UNIQUE { Design. Uniqueness. Innovation } DIRECT Software motion detector can observe and detect motion without any external sensors using any camera – image changes with the time. Camera power that is used for motion detection should be constantly on to let the monitor log image changes and detect motion. -
Page 12: Snapshots And Records Playback
UNIQUE { Design. Uniqueness. Innovation } DIRECT Every video source has its own image settings: Select «Record files» or «Snapshot files» icon, then press file name to start playing. Brightness – parameter range from 0 to 50, 25 used by default. While playing press button to go back to the les list. -
Page 13: External Sensors Motion Detection Recording
UNIQUE { Design. Uniqueness. Innovation } DIRECT 7. Manual and automatic recording 9. Limited warranty User can take snapshots or record video during monitoring door panel or CCTV camera. Press Manufacturer guarantees product normal functioning during the warranty period if the user keeps all safety icon on the screen to take snapshot or press icon on the screen to start video recording.
