Identification

1. Lock Pin
2. Pressing Head
3. Housing
4. Retract Button
5. LED Indicator (red)
6. Battery
7. Trigger
8. LED Work Light (white)

Specifications

Pressing Tool
Length........................................................................................................ 14.45" (367 mm)
Width ............................................................................................................. 2.95" (75 mm)
Depth ......................................................................................................... 12.48" (317 mm)
Weight (with battery) ....................................................................................... 7.8 lb (3.5 kg)
Operating Force ............................................................................................ 3.6 ton (32 kN)
Hydraulic Oil .......................................................................... Biodegradable hydraulic fluid
Recommended Operating Temperature Range ..................5 °F to 122 °F (–15 °C to 50 °C)
Battery Charger ........................................................................ Read the instructions supplied
Greenlee / A Textron Company
2
1
8
7
Pistol Grip Battery-powered Pressing Tool
3
5
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
4
5
6
with the battery charger
