- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® MR16 HydraPro™ Well Light (Lamp Ready) ® AWL-705-25-BBZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE AMP® MR16 HydraPro™ Well Light (Lamp Ready) AWL-705-25-BBZ Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents B. (1) PVC Tube A. (1) Fixture Parts Required (sold separately) A. (1) MR16 Lamp Product Dimensions 6.25” 8.25” 5.5” Remove Faceplate and Lens Loosen the thumb screws and slide the housing down to the end of the brackets. Then untighten the Screw faceplate screws and remove the Faceplate...
- Page 4 INSTALLATION & MAINTENANCE GUIDE AMP® MR16 HydraPro™ Well Light (Lamp Ready) AWL-705-25-BBZ Install Bulb Insert the bulb with the correct MR16 Bulb wattage and type marked on the fixture label. CAUTION: Do not exceed the maximum wattage marked on luminaire label.
- Page 5 Wire Connection Place the fixture onto the PVC Tube. PVC Tube Fixture Pass the luminaire pigtail through the PVC tube. Strip both leads from the luminaire pigtail. Using two wire connectors (sold seperately), connect the leads from the luminaire to main supply cable leads.
- Page 6 customersupport@amplighting.com • 813.978.3900 –6–...
- Page 7 w w w. a m p l i g h t i n g . c o m –7– –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2018, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m is-AWL-705-BBZ-ver4.pdf...
