Click on [Add] button to confirm settings. Connections shall be saved (and inserted in
table). From this time on program shall enable wires connection with device and
reading, and saving of parameters in Active Track Basic+ memory will be possible.
7.2.2.5.2.

Remote connection

As provided above the device and software makes for complete configuration with
GPRS link or CSD channel. This programming mode requires definition of linking
parameters.

7.2.2.5.2.1. GPRS linking

Activate file in main menu and select "Connection" function (or after clicking on
icon on fast access bar) and click on "GPRS" tab to carry out configuration of this
mode.
On screen the following window shall appear.
Define:
Name of connection e.g.: Remote

Select name of analyzer e.g.: Primary

Enter analyzer address e.g.: www.ebs.pl

Enter port on which analyzer operates e.g. 9000

Click on [Add] button to confirm settings. Connections shall be saved (and inserted in
table). From this time on program shall enable remote connection to device and
reading and saving of parameters in Active Track memory shall be possible.
Note:
The following parameters: analyzer name, analyze address, port relate to
settings of OSM.Server receiver of monitoring system. Remote programming is
available only if above mentioned device (or software) is used.

7.2.2.5.2.2. CSD linking

Activate file in main menu and select "Connection" function (or after clicking on
icon on fast access bar) and click on "GSM Modem" tab to carry out configuration of
this mode.
On screen the window shall appear where it is possible to define:
 Name of connection e.g. Remote CSD
 Serial port where GSM modem is connected (e.g. Wavecom Fastrack)
 PIN code of SIM card installed in GSM modem e.g. 1111
20
