Product Specification - Steelcase Flex collection User Manual

SYNCHRONIZING LIFTING COLUMNS:
• Operate the desk all the way down to the lowest position, and release.
• Press down on the controller, and hold.
• After two seconds, the desk will move up and down, settling to its correct
'bottom' position.
• The lifting columns are now synchronized via the software in the control box.
• Operate the desk all the way up and down to confirm proper function.

PRODUCT SPECIFICATION

Range of Adjustment
Distributed Weight Capacity
Tip: When calculating lifting
capacity, subtract the weight of
the worksurface, understructure
and options.
Wire Management
Controller
Decibel Rating
Volts
Frequency & Phase
Amps
Watts
Standby Power
Adjustability Speed
Duty Cycle
* See spec guide for weight of each feature or refer to label on the underside of
the worksurface for weight limits on the desk.
Basic Height: 27.6" – 46.9"
(701.04 mm – 1,191.04 mm)
Extended Height: 22.6" – 48.7"
(574 mm – 1,237 mm)
Base supports a maximum distributed
weight load of:
360 lbs (163.1 kg)*
Optional
Simple Touch, Active Touch
< 55 dBA
120V AC
60 Hz, Single-Phase
2.5A
300W
0.1W
1.5"/sec. (38.1 mm/sec)
10% (2 min. on, 18 min. off)
