INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
DISCOVERY II WOOD APPLIANCE
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL:
DISCOVERY-II-C
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
R
7033-353D
WARNING
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
•
Do not over-fire - If appliance or chimney connector
glows, you are over-firing. Over-firing will void
your warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room
as appliance.
•
Alert children and adults to hazards of
high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over-fire and generate
poisonous gases (i.e. carbon monoxide).
NOTE: To obtain a French translation of this
manual, please contact your dealer or visit
www.quadrafire.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre
revendeur ou visitez
www.quadrafire.com
September 25, 2019

Advertisement

Table of Contents
loading

Related Manuals for Hearth & Home Quadra-Fire DISCOVERY-II-C

Summary of Contents for Hearth & Home Quadra-Fire DISCOVERY-II-C

  • Page 1 Owner’s Manual Operation & Care INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. Contact your dealer with questions on installation, operation, or service. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is not followed exactly, a fire could result causing property damage, personal injury,...

  • Page 2: Sample Of Serial Number / Safety Label

    Discovery II NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label LOCATION: Back of appliance ITEM PART NUMBER PART NAME 7033-354 SERIAL RATING PLATE CAUTION HOT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN AND CLOTHING AWAY. CONTACT MAY CAUSE SKIN BURNS. KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL FAR AWAY FROM THE APPLIANCE.

  • Page 3: Table Of Contents

    Discovery II Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

  • Page 4: Warranty Policy

    Discovery II B. Warranty Policy Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: WARRANTY PERIOD: distributor, whichever occurs earlier.
  • Page 5 Discovery II WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. •...
  • Page 6 Discovery II This warranty is void if: • • • There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited LIMITATIONS OF LIABILITY • have other rights, which vary from state to state. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN.

  • Page 7: Quick Start Guide

    Discovery II C. Quick Start Guide NOTE: These are generic drawings and may not represent your specifi c model. 10 Pieces of Newspaper, 10-20 Pieces of Dry ITEMS NEEDED FOR FIRST FIRE: Kindling and Few Pieces of Dry Split Wood. OPEN AIR CONTROLS LOAD WOOD...

  • Page 8: Listing And Code Approvals

    Discovery II Listing and Code Approvals A. Appliance Certification B. BTU & Efficiency Specifications Model: Discovery II Wood Appliance EPA Certification 86-17 Number: Laboratory: OMNI Test Laboratories, Inc. EPA Certified Emissions: 1.9 grams per hour Report No & Date: 0061WS066S *LHV Tested Efficiency: 78.3% Listed Room Appliance, Solid Fuel Type:...

  • Page 9: Glass Specifications

    Discovery II C. Glass Specifications WARNING This appliance is equipped with 5mm ceramic glass. Replace glass only with 5mm ceramic glass. Please contact your dealer for replacement glass. Fire Risk. Hearth & Home Technologies disclaims any D. Mobile Home Approved responsibility for, and the warranty will be •...

  • Page 10: Operating Instructions

    Discovery II User Guide Operating Instructions A. Over-Firing Your Appliance Dead wood lying on the forest floor should be considered wet, and requires full seasoning time. Standing dead wood WARNING can be considered to be about 2/3 seasoned. To tell if wood is dry enough to burn, check the ends of the logs.

  • Page 11: Air Controls

    Discovery II 2. Second Stage E. Using Burn Rate Air Control & ACC System The next stage of burning, the secondary stage, is the 1. Start up and Reloading Fuel period when the wood gives off flammable gases which Open both Burn Rate Air Control and ACC systems fully. To burn above the fuel with bright flames.

  • Page 12: Burn Rates And Operating Efficiency

    Discovery II F. Burn Rates and Operating Efficiency WARNING For maximum operating efficiency This wood appliance has a manufacturer-set minimum low burn rate that must not be altered. It is against federal Risk of Fire. regulations to alter this setting or otherwise operate this When set on High Burn Rate and over-riding wood appliance in a manner inconsistent with operating the Automatic Combustion Control system an...

  • Page 13: Building A Fire

    Discovery II G. Building A Fire NOTE: Before lighting your first fire in the appliance: • Build fire on brick firebox floor. • Do NOT use grates, andirons or other methods to NOTE: The special high temperature paint that your support fuel.

  • Page 14: Blower Operating Instructions

    Discovery II H. Blower Operating Instructions I. Opacity (Smoke) This is the measure of how cleanly your appliance is NOTE: If your Quadra-Fire wood appliance is equipped burning. Opacity is measured in percent; 100% opacity is with an optional blower, you should follow when an object is totally obscured by the smoke column these guidelines: from a chimney, and 0% opacity means that no smoke...

  • Page 15: Clear Space

    Discovery II J. Clear Space K. Negative Pressure • Do NOT place combustible objects within 4 ft (1.2 m) of WARNING the front of appliance (Figure 15.1). • Mantel - avoid placing candles and other heat-sensitive Asphyxiation Risk. objects on mantel or hearth. Heat may damage •...

  • Page 16: Frequently Asked Questions

    Discovery II L. Frequently Asked Questions ISSUES SOLUTIONS When first operated, this appliance may release an odor for the first several hours. This is Odor from appliance caused by the curing of the paint and the burning off of any oils remaining from manufacturing. Noise is caused by metal expanding and contracting as it heats up and cools down, similar to Metallic noise the sound produced by a furnace or heating duct.

  • Page 17: Maintenance And Service

    Discovery II Maintenance and Service A. Quick Reference Maintenance Guide CAUTION When properly maintained, your fireplace will give you many years of trouble-free service. Contact your Allow the appliance to completely cool down before dealer to answer questions regarding proper operation, performing any cleaning or maintenance.

  • Page 18: General Maintenance

    Discovery II B. General Maintenance 2. Disposal of Ashes • Frequency: When ash is within 1-3/4 in. (44mm) of 1. Creosote (Chimney) Cleaning firebox lip • Frequency: Every 2 months during heating season or • By: Homeowner as recommended by a certified chimney sweep; more frequently if chimney exceeds or is under 14-16 ft.
  • Page 19 Discovery II 4. Glass Cleaning 6. Inspect Firebrick • Frequency: As desired • Frequency: After each ash removal • By: Homeowner • By: Homeowner Replace the firebrick if they become crumbly and/or if there CAUTION is a 1/4 inch (6.35mm) gap between the bricks. Handle glass assembly with care.

  • Page 20: Correct Baffle & Blanket Placement

    Discovery II INCORRECT POSITIONS C. Correct Baffle & Blanket Placement WARNING Fire Risk. Firebox damage due to improper baffle placement is not covered by warranty. Operate the wood burning appliance with the baffle in the correct position only. Not doing so could result in: •...

  • Page 21: Troubleshooting Guide

    Discovery II Troubleshooting Guide With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken.

  • Page 22: Service Part Replacement

    Discovery II Service Part Replacement A. Glass Replacement B. Firebrick Replacement NOTE: Replace with 5mm ceramic glass only. Service Part: SRV7033-006 Service Part: 7000-012 Replace the firebrick if they become crumbly and/or if there is a 1/4 inch (6.35mm) gap between the bricks. 1.

  • Page 23: Snap Disc Replacement

    Discovery II C. Snap Disc Replacement Service Part: SRV230-0470 1. Locate the snap disc bracket assembly at the bottom left rear corner of the appliance. 2. A magnet holds the bracket to the appliance. Pull the bracket down away from the appliance to expose the snap disc.

  • Page 24: Decorative Panel Removal & Installation

    Discovery II E. Decorative Panel Removal & Installation Tile Frame Service Part: SRV7033-324 Blank Frame Service Part: SRV7033-346 Your appliance ships with two different side options, one is a solid side panel (Figure 24.1) and tile side panel (Figure 24.2). There are two of each and no left or right side, these can be changed at anytime.

  • Page 25: Door Handle Assembly

    Discovery II F. Door Handle Assembly G. Tube Channel Assembly Replacement Service Part: SRV7033-071 Service Part: SRV7033-023 1. Slide door handle through door. Removing Tube Channel Assembly 2. Install additional washer(s) as shown in Figure 25.1 1. Remove the right side shield by removing 2 screws in 3.

  • Page 26: Reference Materials

    Discovery II Reference Materials A. Service and Maintenance Log Date of Service Performed By Description of Service 7033-353D September 25, 2019...

  • Page 27: Exploded View

    Discovery II B. Exploded View DISCOVERY-II-C Service Parts Beginning Manufacturing Date: June2017 Wood Stove Ending Manufacturing Date: Active Part number list on following page. 07/19 September 25, 2019 7033-353D...

  • Page 28: Service Parts

    Discovery II C. Service Parts DISCOVERY-II-C Service Parts Beginning Manufacturing Date: June2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 29 Discovery II DISCOVERY-II-C Service Parts Beginning Manufacturing Date: June2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 30 Discovery II DISCOVERY-II-C Service Parts Beginning Manufacturing Date: June2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Stocked Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.

  • Page 31: Accessories

    Discovery II D. Accessories DISCOVERY-II-C Service Parts Beginning Manufacturing Date: June2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 32 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
