E. Power Cord
The power cord is shipped assembled to the appliance.
You may route the power cord either to the left or right
side depending on your configuration for power source
INSTALLER: Leave this manual with party responsible for use and operation.
(Figure 20.1). NOTE: Power cord is 96 inches in length.
OWNER: Retain this manual for future reference.
EXPEDITION I WOOD INSERT
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBER:
EXPEDITION-AU
Figure 20.1
F. Flat Surround
Overall Dimensions
Small Size 38" x 28"
Standard Size 43" x 31"
1. Lay surround face down on a protected surface to
prevent scratching.
2. Remove door from front of appliance and set aside laying
it onto a protective surface (Figure 20.2).
3. Remove face from front of appliance and set aside laying
it onto a protective surface (Figure 20.2).
4. Lift surround to front of appliance (Figure 20.3).
5. Reinstall face to front of appliance and then the door.
11/23 1 20
Installation Manual
Installation & Appliance Set-Up
