Hearth & Home Simplifyre SFE-ST Homeowner's Installation & Operating Manual

Builder box

Advertisement

Model: SFE-ST
INSTALLER/CONSUMER SAFETY
INFORMATION
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND USING APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, AN ELECTRICAL SHOCK
OR FIRE MAY RESULT, CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.

FOR YOUR SAFETY

SERVICE MUST BE PERFORMED BY
A QUALIFIED SERVICE AGENCY.
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
INSTALLER: DO NOT DISCARD THIS MANUAL -- LEAVE FOR HOME OWNER
1
US
C
ANSI / UL1598-2004
Hearth & Home Technologies Inc. • SFE-ST • 4050-510 Rev A • 05/08
BUILDER BOX
TUV Listed as SFE-ST
Homeowner's Installation & Operating Manual
Note: The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
