INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE:
DO NOT discard this manual!
Model(s):
WOODBURNING FIREPLACE
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recomends HHT
Factory Trained or NFI certified professionals.
Owner's Manual
Operation and Care
Majestic Biltmore Series • SB100 Owner's Manual • 4013-304 • Rev H • 02/20
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• DO NOT overfire. Overfiring will void your
warranty.
• Comply with all minimum clearances to com-
bustibles as specified. Failure to comply may
cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fireplace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other flammable
materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate
poisonous gases (i.e. carbon monoxide).
1
Advertisement
Table of Contents
Related Manuals for Hearth & Home Majestic SB100
Summary of Contents for Hearth & Home Majestic SB100
- Page 1 Owner’s Manual Operation and Care INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. Contact your dealer with questions on installation, operation, or service. NOTICE: DO NOT discard this manual! WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury, or death.
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... -
Page 3: Welcome
Welcome Read this manual before installing or operating this fireplace. Please retain this owner’s manual for future references. A. Congratulations Congratulations on selecting a HHT wood burning fire- This Owner's Manual should be retained for future refer- place. The HHT fireplace you have selected is designed to ence. -
Page 4: Limited Lifetime Warranty
► B. LIMITED LIFETIME WARRANTY Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installa on, and to any transferee taking ownership of the appliance at the site of installa on within two years following the date of original purchase, that the HHT appliance will be free from... - Page 5 WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installa� on. •...
-
Page 6: Product Specific And General Information
Product Specific and General Information B. Gas Log Sets, Gas Inserts, Gas Log Light- A. Appliance Certification ers, Wood-burning Inserts This fireplace system has been tested and listed in accor- • Optional dance with UL 127 standards by Underwriters Laboratories Inc. -
Page 7: Important Safety And Operating Information
Important Safety and Operating Information Fireplace Safety 1. Clear Space Combustible materials must not be stored on the hearth Most problems are caused by improper installation and op- extension. Room furnishings such as drapes, curtains, eration of the fireplace. To provide reasonable fire safety, chairs or other combustibles must be at least 4 ft the following should be given serious consideration: (1219 mm) from the front of the fireplace. -
Page 8: Grate
2. Grate 7. Over-Firing Your Fireplace This fireplace is designed to be used with the supplied WARNING! Risk of Fire! Do not over-fire. grate or one approved by HHT. Over-firing may ignite creosote or will damage the WARNING! Risk of Fire! fireplace and chimney. -
Page 9: General Operating Parts
WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass will cause burns. • DO NOT touch glass until it is cooled • NEVER allow children to touch glass • Keep children away • CAREFULLY SUPERVISE children in same room as fireplace. -
Page 10: Flue Damper
1. Flue Damper The flue damper must be in the fully opened position (handle up toward the top of the fireplace) during op- eration of the fireplace. Before lighting the fireplace, verify fully open position by looking up from the inside of the fireplace. 2. -
Page 11: Fuel
C. Fuel WARNING! Risk of Fire! • DO NOT burn wet or green wood. WARNING! For use with solid wood fuel only. • Wet, unseasoned wood can cause accumulation of Other fuels may overfire and generate poisonous gases (i.e. creosote. carbon monoxide). -
Page 12: Seasoning
3. Seasoning 5. Burning Process Seasoned firewood is nothing more than wood that is Fire requires fuel, air and heat. If heat is robbed from cut to size, split and air dried to a moisture content of the fireplace during the drying stage, the new load of around 20%. -
Page 13: Lighting Instructions
E. Lighting Instructions NOTICE: You must establish a good draft to prevent smoke spillage into the room. The first three or four fires should be of moderate size to allow the oils and binders to be burned from the fireplace and the refractory and paint to cure. -
Page 14: Maintenance And Service
Maintenance and Service B. Creosote (Chimney) Cleaning WARNING! Hot Surfaces! Frequency: As needed; at least annually before light- Glass and other surfaces are hot during operation AND cool ing, or once every two months during heating season. down. DO NOT clean fireplace until it is cooled. When creosote has accumulated it shall be removed to Installation and repair should be done by a qualified service reduce the risk of a chimney fire. -
Page 15: Grate
Remove 2 screws from Remove 8 screws Remove 4 screws the front and back and and lift top. and lift top pan off. Remove screws, lift the top off. lift top cover. Top Cover Chimney Screw Slip Section TR11/TR11T TCT1175 ST1175 Round Termination Cap DTO/DTS Series... -
Page 16: Troubleshooting
Troubleshooting Start Fire Problems Possible Cause Solution Can’t get fire started Not enough kindling/paper or no Use dry kindling, more paper. Arrange kindling & wood for Excessive smoke or spillage kindling/paper air movement. Burns too slowly Damper closed/not fully open Open damper. -
Page 17: Faqs
A. FAQs Hearth & Home Technologies assumes no responsibil- Be sure you have air available for combustion and that ity for the improper performance of the fireplace sys- your firewood is dry and well seasoned. Build your fires tem caused by inadequate draft due to environmental properly and according to the instructions given in op- conditions, down drafts, tight sealing construction of erating instructions, “Starting a Fire”. - Page 18 Overhanging tree? Bird's nest or leaves in termination cap? Structural changes in Another appliance in chimney area? home also exhausting air (furnace, fan, Unsealed dryer, etc.)? can lights? Overhead fan operating? Creosote buildup in flue? Air register from furnace near fireplace? Doors opening and closing?
-
Page 19: Reference Materials
Reference Materials A. Service Parts ► BILTMORE (SB100, SB100HB) Service Parts Beginning Manufacturing Date: N/A 50” Woodburning Fireplace Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. - Page 20 BILTMORE (SB100, SB100HB) Service Parts Beginning Manufacturing Date: N/A Ending Manufacturing Date: Active Traditional Herringbone IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor. ITEM DESCRIPTION COMMENTS...
-
Page 21: Accessories
B. Accessories Doors DM100 Bi-fold Glass Doors with Black Trim Grand Vista Cabinet Style Mesh Doors, black or bronze Contour Cabinet Style Mesh Doors, black or bronze GV100BK CONTOUR100BK CONTOUR100BZ Gas Inserts Gas Log Sets Gas Log Lighters Wood-burning Inserts Majestic Biltmore Series •... - Page 22 This page intentionally left blank. Majestic Biltmore Series • SB100 Owner’s Manual • 4013-304 • Rev H • 02/20...
- Page 23 This page intentionally left blank. Majestic Biltmore Series • SB100 Owner’s Manual • 4013-304 • Rev H • 02/20...
-
Page 24: Contact Information
C. Contact Information Majestic, a brand of Hearth & Home Technologies 7571 215th Street West, Lakeville, MN 55044 www.majesticproducts.com Please contact your HHT dealer with any questions or concerns. – NOTES – CAUTION DO NOT DISCARD THIS MANUAL • Important operating •...
