6. Introduction to "image" sub-menu

6.1. View image

171229-105030
171229-105031
171229-105032
171229-105033
As shown in the figure, press " /MENU" key to select "image" option in the
main menu. Then press " " key to enter image list. Press "
key in navigation to select the image. Then press "SELECT/ENTER" key to
view image. When viewing the images, press "
image. Press " " to view the next image. Press "SELECT/ENTER" key to
return. Press " /MENU " key to exit from the menu.

6.2. Delete images

When viewing the images, the screen will show the prompt of "Delete photo？
" by pressing " " key. If "yes" is selected at the moment, press "
key to determine to delete the image. If "no" is selected, press
"SELECT/ENTER" key to determine not to delete the image.
www.xintest.com.cn
"or " "
" key to view the precious
/MENU"
8

7. Introduction to "color palette" sub-menu

7.1 Color Palette Description

The menu of color palette can change the false color of infrared thermal
image. The product provides five types of color palette: rainbow, iron oxide
red, cold color, white heat and black heat.
Suitable selection of color palette displays the details of the target objective
better. Rainbow, iron oxide red and cold color palettes focus on display of
color. Such color palettes are very suitable for high heat contrast and are
used to improve the color contrast between high temperature and low
temperature. But the black & white and white & black color palettes provide
even linear color.
The following is the image of the same object with selection of different
color palettes.
Rainbow Iron oxide red
White heat Black heat
9
www.xintest.com.cn
Cold color
