Related Manuals for Modern Fan Co Velo DC VEL Series
Summary of Contents for Modern Fan Co Velo DC VEL Series
- Page 1 A note about our online installation instructions: Most Modern Fan Co. products have been in our assortment for several years or longer. As we continually work to improve product performance and user experience, we occasionally introduce subtle (and sometimes dynamic) product changes. These can affect the steps associated with assembly and installation of our products depending on when a fan was produced.
- Page 2 Velo DC Installation Instructions and Owners Manual Models: VEL–XX–XX–XX–XX(X)–XX Net Weight of Fan: 14.0 lbs (6.4 kgs) Please read and save these instructions. If you have any questions while installing your fan, call us first! Customer Service Monday–Friday, 8am–4pm (PST) tel 888-588-3267 Safety Instructions and Warnings ..2 Fan Installation ..........4...
- Page 3 ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. Use this unit only in the manner intended by the manufacturer. If you have any questions contact the Modern Fan Co at (888) 588-3267. Use only Modern Fan Co replacement parts. ...
- Page 4 Installation Preparation WARNING Fan Location Make sure the installation site you choose allows the fan blades to rotate without any obstruction. Allow a minimum clearance of 7 feet (2.1 meters) from the floor to the blades and 30 inches Minimum of (76 cm) from the wall to the 7 feet (2.1m) end of the blades.
- Page 5 Fan Installation Tools Needed A stepladder, phillips head screwdriver and a Instructions wire stripper Remove and identify contents of carton. blades canopy top cover fan body hanging bracket bottom control(s) include 2 or 3 pieces down rods half-ball balancing hardware package Optional Light Kit parts: glass...
- Page 6 See Page 2 Circuit Breaker WARNING POWER OFF If your fan was ordered with the optional LED light, it should be pre-installed. However, if the LED components are not installed, begin by removing the bottom mounting cup. Route 2-pin connector through center hole on LED board and carefully insert into terminal.
- Page 7 Fan Installation (continued) Run lead wires through center hole of top cover and carefully slide over down rod until resting on fan body. Tighten set screw to hold top cover in place. Run wires through center hole of canopy and gently set canopy on fan body. Run lead wires through half-ball, reinstall stopper pin and tighten half-ball set screw while lifting half ball upward with stopper pin properly positioned in slot.
- Page 8 Circuit Breaker See Pages 2-3 WARNING POWER OFF Identify control components from control package(s). In addition to a receiving unit, your fan may have been ordered with a wall control (transmitter), a handheld remote control (transmitter) or both. receiving unit receiving unit handset switch...
- Page 9 See Pages 2-3 Circuit Breaker Fan Installation WARNING POWER OFF (continued) Dimming Selector Switch The remote handset and wall control ship pre-set for “on/off” operation of the light. The LIGHT button will turn the light on and off when pressed and released. To enable dimming function on the remote handset, move the vertically oriented dip switch down from ON to 1 (or from X to D).
- Page 10 Align threaded rod in bottom cap with center hole on fan body and rotate until tight against fan body. If your fan has the LED light kit, align slots in glass diffuser with studs on fan body, press up and gently rotate into place. There is no need to forcefully over tighten glass bottom cap glass diffuser...
- Page 11 Fan Installation (continued) Fan Operation The ON/OFF switch on the bottom of your wall control (transmitter) terminates power to the fan. This switch must be in the “ON” position for your fan to receive commands and to operate. Alternatively, you may use an on/off toggle switch at the wall box in combination with a remote control handset (transmitter).
- Page 12 Fan Balancing The rotor and motor of your fan have been dynamically tested and balanced during manufacturing and production. In addition, the blades have been matched to the nearest gram to ensure well balanced operation. Furthermore, a blade balancing kit has been included with your fan. Please refer to the instructions packaged with the balancing kit should your fan require additional balancing.
- Page 13 Next, review the troubleshooting tips listed below. As stated in the warranty, Modern Fan Co. is not liable for costs incurred related to installation labor or equipment. Be sure to test all functions of your fan, and if need be, contact customer service while your contractor/electrician is still on site.
- Page 14 Fan makes repetitive ticking noise... • Check for obstructions in rotor path. • Make sure mounting hardware at ceiling is secure. • Make sure all other hardware and blade attachments are tight. • Give fan adequate “break in period” of several hours to several days then repeat steps above.
- Page 15 The Modern Fan Co. directly. • If a noise develops over time (clicking, ticking, humming or otherwise), refer to the troubleshooting section of this manual (pages 12-13).
- Page 16 Lifetime Limited Warranty All products manufactured and sold by The Modern Fan Co. meet the highest industry standards. We use only the finest materials and production processes resulting in quality ceiling fans backed by the following warranty: Motors (dry locations): .......................Lifetime Motors (damp locations): ....................
- Page 17 The Modern Fan Company, Inc. 709 Washington Street, Ashland, Oregon 97520 tel 888-588-3267, fax 541-482-8418 info@modernfan.com modernfan.com V2019/01...
