PCM-9386 Celeron® M 3.5" SBC with MIO/VGA/
LCD/LVDS Ethernet/USB2.0 and SSD
Startup Manual

Packing List

Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-9386 SBC
• 1 Startup manual
• 1 Utility CD
• 1 Mini jumper pack
• 1 Audio cable
• 1 IDE 44 pin
• 1 USB 2 port cable
• 1 Parallel port cable
• 1 Keyboard/Mouse cable
• 1 26-34 pin FDD adapter
• 1 FDD Cable for Slim FDD
• 1 Flat cable 34 pins for FDD
• 1 second serial port cable
• 1 ATX power cable 20P-12P
cable
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-9386, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html (Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCM-9386 Series Rev. A1.
Part No. 2006938601

Standard SBC Functions

• CPU: Embedded ULV Intel Celeron M 600 MHz (0 L2
• System Memory: 1 x SODIMM socket, supports Double
p/n: 9689000002
p/n: 1703100152
• 2nd Cache Memory: Depends on CPU type from 0 to
p/n: 1701440351
p/n: 1703100121
• System Chipset: Intel 852GM GMCH/ICH4 chipset
p/n: 1700260250
• BIOS: Award 4Mbit Flash BIOS
p/n: 1700060202
• Watchdog Timer: 255 levels timer interval
p/n: 9681000044
• Expansion Interface: MIO Interface, Integrated PCI 2.0,
p/n: 1701260125
p/n: 1701340700
• Battery: Lithium 3V/196 mAH
p/n: 1701140201
• Power management: Supports power saving modes
p/n: 1700000265
• Enhanced IDE interface: One channel supports up to
• Optional FDD Interface: Supports one FDD
• Serial ports: Two serial RS-232 ports, COM1: RS-232,
• Parallel port: One parallel port, supports SPP/EPP/ECP
• Keyboard/mouse connector: Supports one standard
• Audio: Supports AC97 Audio stereo sound
• USB: Three USB 2.0 compliant universal serial bus

Solid State Disk

• Supports one 50-pin socket for CFC type I/II

VGA/LVDS Interface

• Chipset: Intel 852GM GMCH
• Memory Size: Optimized Shared Memory Architecture,
• Resolution:
• CRT display Mode: pixel resolution up to
• LVDS display mode: up to UXGA panel resolution
• LVDS: Supports 2 channel 36-bit
• Dual Independent Display: CRT+LVDS
2nd Edition
Oct.
2005.

Specifications

cache)
Embedded ULV Intel Celeron M 373 1.0 GHz (512KB L2
cache)
Data Rate (DDR) 128 MB to 1GB, DDR200/266/333
DRAM
512KB
LPC, USB2.0, SMBus, AC97 and DVO Bus
including Normal/Standby/Suspend modes. APM 1.2,
ACPI compliant.
two EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports UDMA 33 mode
COM2: RS-232/422/485
mode
PC/AT keyboard and a PS/2 mouse
ports
supports up to 64MB frame buffer using system memory
1600 x 1200 @85-Hz and 2048 x 536 @75Hz
with frequency range from 25 MHz to 112 MHz
PCM-9386 Startup Manual
CRT+DVI (w/MIO-254)
LVDS+DVI (w/MIO-254)
1
