Advantech PCM-9381 Startup Manual

PCM-9381 Pentium® M 3.5" SBC with PCI-104/
VGA/LCD/LVDS Ethernet/USB2.0 and SSD
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-9381 SBC
• 1 Startup manual
• 1 Utility CD
• 1 Mini jumper pack
• 1 Audio cable
• 1 IDE 44 pin
• 1 USB 2 port cable
• 1 Parallel port cable
• 1 Keyboard/Mouse cable
• 1 second serial port cable
• 1 ATX power cable 20P-12P
cable
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-9381, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html (Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCM-9381 Series Rev. A1.
Part No. 2006938101

Standard SBC Functions

• CPU: Embedded Intel Pentium M (Banias/Dothan) /LV/
p/n: 9689000002
p/n: 1703100152
p/n: 1701440351
p/n: 1703100121
p/n: 1700260250
p/n: 1700060202
• System Memory: 1x SODIMM socket, support ECC
p/n: 1701140201
p/n: 1700000265
• 2nd Cache Memory: Depends on CPU type from
• System Chipset: Intel 855GME GMCH/ICH4 chipset
• BIOS: Award 4Mbit Flash BIOS
• Watchdog Timer: 255 levels timer interval
• Expansion Interface: PCI-104
• Battery: Lithium 3V/196 mAH
• Power management: Supports power saving modes
• Enhanced IDE interface: One channel supports up to
• Serial ports: Two serial RS-232 ports, COM1: RS-232,
• Parallel port: One parallel port, supports SPP/EPP/
• Keyboard/mouse connector: Supports one standard
• Audio: Supports AC97 Audio stereo sound
• USB: Three USB 2.0 compliant universal serial bus
Solid State Disk
• Supports one 50-pin socket for CFC type I
2nd Edition
Oct. 2005
Specifications
ULV Celeron M Processor supporting Front Side Bus
(FSB) 400MHz
Onboard Celeron M 600 (512K)
Onboard Pentium M 1.1G
Socket 478(*), Ethernet
Optional:
Penitum M 745 1.8GHz
Pentium M 1.6GHz
Pentium M 738 1.4GHz
Celeron M 320 1.3GHz
*: socket 478 for Intel uFCPGA2
Double Data Rate (DDR) 128 MB to 1GB, DDR200/266/
333 DRAM
512KB to 2 MB
including Normal/Standby/Suspend modes. APM 1.2,
ACPI compliant, Supports Enhanced Intel Speed Step
Technology.
two EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports UDMA 33 mode
COM2: RS-232/422/485
ECPmode
PC/AT keyboard and a PS/2 mouse
ports
PCM-9381 Startup Manual
PCM-9381F-M0A1
PCM-9381F-S1A1
PCM-9381F-00A1
1
