Manual
ADVANTECH
PCM-9376
The information contained in this document has been carefully researched and is, to the best
of our knowledge, accurate. However, we assume no liability for any product failures or
damages, immediate or consequential, resulting from the use of the information provided
herein. Our products are not intended for use in systems in which failures of product could
result in personal injury. All trademarks mentioned herein are property of their respective
owners. All specifications are subject to change without notice.
Advertisement
Table of Contents
Related Manuals for Advantech PCM-9376
Summary of Contents for Advantech PCM-9376
- Page 1 Manual ADVANTECH PCM-9376 The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or consequential, resulting from the use of the information provided herein.
- Page 2 User Manual PCM-9376 AMD G-Series T16R 3.5" SBC, DDR3 SODIMM, PC/104, 48-bit LVDS, VGA, 18-bit TTL, 2GbE, Mini PCIe, mSATA, LPC, iManager...
- Page 3 The documentation and the software included with this product are copyrighted 2014 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
- Page 4 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
-
Page 5: Packing List
Packing List Before installation, please ensure the following items have been shipped: Item Part Number 1 PCM-9376 SBC 1 Startup manual 1 Pack of mini jumper Cables Part Number Description 1700019414 COM2 cable 2*5P-2.0/D-SUB, 30cm 1701200220 COM3/4 cable 2*10P-2.0/D-SUB*2, 22cm... - Page 6 Caution! There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the man- ufacturer. Discard used batteries according to the manufacturer's instructions. PCM-9376 User Manual...
- Page 7 PCM-9376 User Manual...
-
Page 8: Table Of Contents
Embedded Controller Configuration..........28 3.4.9 Super I/O Configuration .............. 29 3.4.10 IT8888 Configuration ..............30 Chipset Configuration................31 3.5.1 North Bridge Configuration ............32 3.5.2 North Bridge LVDS Config Select ..........33 3.5.3 South Bridge ................34 PCM-9376 User Manual... - Page 9 1st MB Memory Map................61 Table B.2: 1st MB Memory Map ..........61 Interrupt Assignments ................61 Table B.3: Interrupt Assignments ..........61 Appendix C Watchdog Timer Programming ..63 EC Watchdog Timer Sample Code............64 PCM-9376 User Manual viii...
-
Page 10: Chapter 1 General Introduction
Chapter General Introduction This chapter gives background information on the PCM-9376. Sections include: Introduction Product Features Specifications... -
Page 11: Introduction
Introduction AMD G-Series T16R single core 615 MHz processor. The PCM-9376 can support DDR3 SODIMM up to 4 GB or 1 GB SDRAM on-board, PC/104, Mini PCIe and LPC (Low Pin Count) expansion, VGA, 48-bit LVDS, 18-bit TTL, 2 GbE, 2 SATAII, mSATA, 2 RS-232/422/485, 2 RS-232, 4 USB2.0, SMBus, I... - Page 12 BIOS AMI 32 Mbit SPI Flash ROM OS Support PCM-9376 supports Win7, WinXP, WinCE 6.0, WEC7, WES7, XPE and Linux Ubuntu 12.04. For further information about OS support, please visit Advantech website: www.advantech.com or contact with technical support center.
-
Page 13: Mechanical Specifications
Operating temperature: 0 ~ 60° C (32 ~ 140° F) Operating humidity: 40° C @ 95% RH Non-condensing Storage temperature: -40 ~ 85° C (-40 ~ 185° F) Storage humidity: 60° C @ 95% RH Non-condensing Block Diagram Figure 1.1 Block Diagram PCM-9376 User Manual... - Page 14 PCM-9376 User Manual...
- Page 15 PCM-9376 User Manual...
-
Page 16: Chapter 2 H/W Installation
Chapter H/W Installation This chapter explains the setup procedures of the PCM-9376 hard- ware, including instructions on setting jumpers and connecting peripherals, as well as switches, indicators and mechanical draw- ings. Be sure to read all safety precautions before you begin the... -
Page 17: Jumpers
Generally, you simply need a standard cable to make most connections. Warning! To avoid damaging the computer, always turn off the power supply before setting jumpers. 2.1.2 Jumper List Table 2.1: Jumper List AT/ATX power supply LCD Power Clear CMOS PCM-9376 User Manual... -
Page 18: Jumper Settings
(1-3)* +3.3 V (3-5) +5 V (3-4) +12 V *: default Clear CMOS Part Number 1653003101 Footprint HD_3x1P_79_D Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS Setting Function (1-2)* * Normal (2-3) Clear COMS *: default PCM-9376 User Manual... -
Page 19: Connectors
2.2.2.2 PC/104 -5/-12 V Power Input (CN2) Supplies main power +5 V to PCM-9376 via 6 x 2-pin connector, and to devices that require +12 V. AT power cable is included in standard packing, but ATX power cable (P/N: 1703200201) is an optional accessory requiring additional order. - Page 20 2.2.2.4 2 x Internal USB (CN6/7) PCM-9376 provides four USB (Universal Serial Bus) 2.0 ports Plug and Play via 5 x 2-pin header connectors which provide 1 A power for each port. The USB interface complies with high speed USB specification Rev. 2.0 which supports 480 Mbps trans- fer rate, and are fuse protected.
- Page 21 The LVDS interface is a 20 x 2-pin board-to-board connector for 48-bit LVDS panel up to 1920 x 1200 at 60 Hz which provides 3.3/5/12V with 1A power. 2.2.2.18 PS/2 (CN24) PCM-9376 provides a standard mini din 6-pin connector that supports both keyboard and PS/2 interface mouse. 2.2.2.19 ATX Power Button (CN25) 2-pin box wafer connector for power switch.
-
Page 22: Mechanical
Mechanical 2.3.1 Jumper and Connector Locations Figure 2.1 Jumper and Connector Layout (Top Side) Figure 2.2 Jumper and Connector Layout (Bottom Side) PCM-9376 User Manual... -
Page 23: Board Dimensions
Figure 2.3 Coastline Layout 2.3.2 Board Dimensions 2.3.2.1 CPU Board Drawing Figure 2.4 Board Dimension Layout (Top Side) unit: mm Figure 2.5 Board Dimension Layout (Bottom Side) PCM-9376 User Manual... -
Page 24: Figure 2.6 Board Dimension Layout (Coastline)
Figure 2.6 Board Dimension Layout (Coastline) PCM-9376 User Manual... - Page 25 PCM-9376 User Manual...
-
Page 26: Chapter 3 Bios Settings
Chapter BIOS Settings... -
Page 27: Introduction
AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, you can modify BIOS settings and control the various sys- tem features. This chapter describes the basic navigation of the PCM-9376 BIOS setup screens. -
Page 28: Entering Setup
BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that your CPU's system status is valid. -
Page 29: Advanced Bios Features Setup
Advanced BIOS Features Setup Select the Advanced tab from the PCM-9376 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>... -
Page 30: Pci Subsystem Settings Configuration
Enabled or disable VGA palette registers snooping. PERR# Generation Enabled or disable PCI device to generation PERR#. SERR# Generation Enabled or disable PCI device to generation SERR#. PCI Express Settings Change PCI express device detail settings. PCM-9376 User Manual... -
Page 31: Acpi Settings Configuration
Enable or disable BIOS ACPI auto configuration. Enable Hibernation Enable or disable hibernation function if OS support. ACPI Sleep State Select the ACPI states used for system suspend. S3 Video Repost Enable or disable video repost. PCM-9376 User Manual... -
Page 32: S5 Rtc Wake Settings
S5 RTC Wake Settings Wake system with Fixed Time Enable or disable system wake on alarm event by user define. Wake system with Dynamic Time Enable or disable system wake on alarm event from 1minutes to 5 minutes. PCM-9376 User Manual... -
Page 33: Trusted Computing
3.4.4 Trusted Computing TPM support Enable or disable TPM support for security. PCM-9376 User Manual... -
Page 34: Cpu Configuration
C6 Mode This item allows you to auto or disable C6 function. CPB Mode This item allows you to auto or disable CPB. Node 0 Information View details of memory information related to node 0. PCM-9376 User Manual... -
Page 35: Ide Configuration
3.4.6 IDE Configuration IDE Configuration Display SATA Port1 / SATA Port2 / M-SATA information. PCM-9376 User Manual... -
Page 36: Usb Configuration
Time-out value for control, Bulk, and interrupt transfers. Device reset time-out USB mass storage device start unit command time-out. Device power-up delay Maximum time the device will take before it properly report itself to the host con- troller. PCM-9376 User Manual... -
Page 37: Embedded Controller Configuration
This item allows you to select backlight mode. EC Watch Dog Function This item allows you to select EC of WDT timer. EC PS2 Device Wake Up This item allows you to enable or disable EC of PS2 device wake up function. PCM-9376 User Manual... -
Page 38: Super I/O Configuration
Serial Port1 / Port2 / Port3 / Port4 address This item allows you to select serial port1 ~ port4 of base addresses. Serial Port1 / Port2 / Port3 / Port4 IRQ This item allows you to select serial port1 ~ port4 of IRQ. PCM-9376 User Manual... -
Page 39: It8888 Configuration
This item allows you to select subtractive decode or positively decode. Memory Hole 15MB-16MB This item allows you to enable or disable memory hole. Distributed DMA Channels This item allows you to enable or disable DMA channels. PCM-9376 User Manual... -
Page 40: Chipset Configuration
Chipset Configuration North Bridge Detail for North Bridge items. North Bridge LVDS Config Select Detail for display items. South Bridge Detail for South Bridge items. PCM-9376 User Manual... -
Page 41: North Bridge Configuration
3.5.1 North Bridge Configuration GFX Configuration Detail of LAN1/LAN2/Mini PCIe, and PSPP Policy items. Memory Configuration Detail of Integrated Graphics, Bank Interleaving items. PCM-9376 User Manual... -
Page 42: North Bridge Lvds Config Select
3.5.2 North Bridge LVDS Config Select TTL Output Mode This item allows you to enable or disable TTL panel function. LVDS Output Select This item allows you to select LVDS panel type of resolution. PCM-9376 User Manual... -
Page 43: South Bridge
Restore on AC Power Loss This item allows you to select system restore states if AC power loss. Wake On Ring / Wake On Lan This item allows you to enable or disable wake on LAN or Ring function. PCM-9376 User Manual... -
Page 44: Boot Settings
Set display mode for option ROM. Interrupt 19 Capture This item allows option ROMs to trap interrupt 19. CSM Support This item allows you to enable or disable CSM support. Boot Option Sets the system boot order. PCM-9376 User Manual... -
Page 45: Security Configuration
Security Configuration Select Security Setup from the PCM-9376 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:... -
Page 46: Save & Exit
This item allows you to save the changes done so far as user defaults. Restore User Defaults This item allows you to restore the user defaults to all the options. Boot Override Boot device select can override your boot priority. PCM-9376 User Manual... - Page 47 PCM-9376 User Manual...
-
Page 48: Appendix A Pin Assignments
Appendix Pin Assignments... -
Page 49: Jumper Setting
Inverter power CN19 SATA power (5V/12V) CN20 SATA power (5V) CN21 Internal GbE CN22 LVDS CN23 External GbE CN24 PS/2 CN25 Power Switch CN26 External COM1: RS-232/422/485 CN27 CN28 Half-size Mini-PCIe CN29 CN30 Full-size mSATA CN31 DDR3 SODIMM PCM-9376 User Manual... - Page 50 PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS Setting Function (1-2)* Normal (2-3) Clear COMS ISA -5V & -12V Input Part Number 1653003101 Footprint HD_3x1P_79_D Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS Pin Name -12V PCM-9376 User Manual...
- Page 51 Internal USB Part Number 1653005260 Footprint HD_5x2P_79_N10 Description PIN HEADER 2x5P 2.0mm 180D(M) SMD 21N22050 Pin Name A_D- B_D- A_D+ B_D+ Internal USB Part Number 1653005260 Footprint HD_5x2P_79_N10 Description PIN HEADER 2x5P 2.0mm 180D(M) SMD 21N22050 Pin Name PCM-9376 User Manual...
- Page 52 A_D- B_D- A_D+ B_D+ COM3/COM4 Part Number 1653004793 Footprint HD_10x2P_79_23N685B-20M10 Description BOX HEADER 10x2P 2.0mm 180D(M)SMD 23N685B-20M10B Pin Name DCD3# DSR3# RXD3 RTS3# TXD3 CTS3# DTR3# RI3# DCD4# DSR4# RXD4 RTS4# TXD4 CTS4# DTR4# RI4# PCM-9376 User Manual...
- Page 53 BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10 Pin Name DCD1# DSR1# RXD1 RTS1# TXD1 CTS1# DTR1# RI1# CN10 GPIO Part Number 1653005201 Footprint HD_5x2P_79_D Description PIN HEADER 5*2P 180D(M) SQUARE 2.0mm Pin Name GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3 PCM-9376 User Manual...
- Page 54 MIC1L CN12 AT Power Input Part Number 1655204030 Footprint WF_4P_200_R1_D Description WAFER 4P 5.08mm 180D(M) DIP 626M-04 Pin Name +12V CN13 SATA Part Number 1654004659 Footprint SATA_7P_WATM-07DBN4A3B8UW_D Description Serial ATA 7P 1.27mm 180D(M) DIP WATM-07DBN4A3B8 Pin Name PCM-9376 User Manual...
- Page 55 WAFER BOX 2.0mm 4P 180D(M) W/LOCK A2001WV2-4P Pin Name SMB_DAT SMB_CLK CN16 PC/104 Part Number 165312022A 165313222A Footprint PC104 PCB SKT 20x2P 2.54mm 180D(F) DIP 962-40202-03 Description PCB SKT 32x2P 2.54mm 180D(F) DIP 962-40322-03 Pin Name IOCHCK PCM-9376 User Manual...
- Page 56 IOCHRDY SA19 SA18 SA17 SA16 SA15 SA14 SA13 SA12 SA11 SA10 RSTDRV IRQ9 DRQ2 -12V 0WS# +12V SMEMW# SMEMR# IOW# IOR# DACK3# DRQ3 DACK1# DRQ1 REFRESH# PCM-9376 User Manual...
- Page 57 SYSCLK CN17 TTL Panel Part Number 1653920200 Footprint SPH20X2 Description B/B Conn. 40P 1.25mm 90D SMD DF13-40DP-1.25V(91) Pin Name +3.3V +3.3V PD10 PD11 PD12 PD13 PD14 PD15 PCM-9376 User Manual...
- Page 58 PD17 PD18 PD19 PD20 PD21 PD22 PD23 SHFCLK FLM (V-SYNC) M/DE LP (H-SYNC) ENVEE CN18 Inverter Power Output Part Number 1655000453 Footprint WHL5V-2M-24W1140 Description WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI Pin Name +12V ENABKL PCM-9376 User Manual...
- Page 59 Footprint WF_2P_79_BOX_R1_D Description WAFER BOX 2P 2.0mm 180D(M) DIP A2001WV2-2P Pin Name CN21 LAN2 Part Number 1653004099 Footprint HD_5x2P_79_23N685B-10M10 Description BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10 Pin Name BI_DD+(GHz) BI_DD-(GHz) BI_DC+(GHz) BI_DC-(GHz) RX+(10/100),BI_DB+(GHz) RX-(10/100),BI_DB-(GHz) TX+(10/100),BI_DA+(GHz) TX-(10/100),BI_DA-(GHz) PCM-9376 User Manual...
- Page 60 +5V or +3.3V or +12V +5V or +3.3V or +12V +5V or +3.3V or +12V +5V or +3.3V or +12V LVDS0_D0- LVDS1_D0- LVDS0_D0+ LVDS1_D0+ LVDS0_D1- LVDS1_D1- LVDS0_D1+ LVDS1_D1+ LVDS0_D2- LVDS1_D2- LVDS0_D2+ LVDS1_D2+ LVDS0_CLK- LVDS1_CLK- LVDS0_CLK+ LVDS1_CLK+ LVDS0_D3- LVDS1_D3- LVDS0_D3+ LVDS1_D3+ PCM-9376 User Manual...
- Page 61 Description PHONE JACK RJ45 8P8C 90D SHIELDED 9743-10811-SE Pin Name BI_DA+(GHz) BI_DA-(GHz) BI_DB+(GHz) BI_DC+(GHz) BI_DC-(GHz) BI_DB-(GHz) BI_DD+(GHz) BI_DD-(GHz) CN24 Part Number 1654003199 Footprint CONTEK_MQN3261F1G400 Description MINI DIN 6P 90D(F) DIP MQN3261F1G400 Pin Name KBDAT MSDAT KBCLK MSCLK PCM-9376 User Manual...
- Page 62 WAFER BOX 2P 2.0mm 180D(M) DIP A2001WV2-2P Pin Name PSIN CN26 COM1 Part Number 1654409108 Footprint SUYIN_070205MR009S202BA Description D-SUB Conn. 9P 5mm 90D(M) 070205MR009S202BA Pin Name DCD# DTR# DSR# RTS# CTS# CN27 Part Number 1654009560 Footprint DSUB_15P_1760015-046-R Description Pin Name GREEN PCM-9376 User Manual...
- Page 63 BLUE DDAT HSYNC VSYNC DCLK CN28 Mini PCIE Part Number 1654002538 Footprint MINIPCIE_HALF_PCM-9376 Description Pin Name WAKE# +3.3VSB +1.5V UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP W_DISABLE# PERST# PERn0 PCM-9376 User Manual...
- Page 64 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3VSB +3.3VSB +1.5V +3.3VSB CN29 Part Number 00A00000830 Footprint LPC_BOARD_PCE-5026_SMD Description Pin Name RESET# FRAME# +3.3V LPC_SERIRQ PWROK PCM-9376 User Manual...
- Page 65 CN30 mSATA Part Number 1654002538 Footprint MINIPCIE_HALF_PICO_ITX Description Pin Name WAKE# +3.3VSB +1.5V UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP W_DISABLE# PERST# PERn0 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DAT PETp0 PCM-9376 User Manual...
- Page 66 USB D- USB D+ +3.3VSB +3.3VSB +1.5V +3.3VSB CN31 SODIMMDDR3RVS_204 Part Number 1651002082 Footprint DDR3_204P_AS0A626-N2 PCM-9376 User Manual...
- Page 67 PCM-9376 User Manual...
-
Page 68: Appendix B System Assignment
Appendix System Assignment... -
Page 69: System I/O Ports
1F0-1F7 IDE Controller 290-29F EC resource 2E8-2EF Serial port 4 2F8-2FF Serial port 2 3C0-3DF System resource 3E8-3EF Serial port 3 3F8-3FF Serial port 1 400-4FF System resource 800-8FF System resource B00-B3F System resource C00-CFF System resource PCM-9376 User Manual... -
Page 70: 1St Mb Memory Map
Interval timer IRQ1 Keyboard IRQ2 Interrupt from controller 2 (cascade) IRQ3 COM2 IRQ4 COM1 IRQ5 COM3 IRQ6 Available IRQ7 Available IRQ8 IRQ9 Reserved IRQ10 Available IRQ11 COM4 IRQ12 Reserved IRQ13 Math Coprocessor IRQ14 Primary IDE IRQ15 Secondary IDE PCM-9376 User Manual... - Page 71 PCM-9376 User Manual...
-
Page 72: Appendix C Watchdog Timer Programming
Appendix Watchdog Timer Programming... -
Page 73: Ec Watchdog Timer Sample Code
EC_Command_Port mov al,89h ; Write EC HW ram. out dx,al mov dx, EC_Data_Port mov al, 57h ; Watchdog event flag. out dx,al mov dx, EC_Data_Port mov al, 04h ; Reset event. out dx,al mov dx, EC_Command_Port PCM-9376 User Manual... - Page 74 ; start WDT function. out dx,al .exit PCM-9376 User Manual...
- Page 75 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...
- Page 76 Our company network supports you worldwide with offices in Germany, Great Britain, Turkey and the USA. For more information please contact: Distec GmbH FORTEC Elektronik AG Augsburger Str. 2b Lechwiesenstr. 9 82110 Germering 86899 Landsberg am Lech Germany Germany Phone: +49 (0)89 / 89 43 63-0 Phone: +49 (0)8191 / 911 72-0...
