Advantech PCM-9380 Startup Manual

PCM-9380 Pentium® M 3.5" SBC with MIO/VGA/
LCD/LVDS Ethernet/USB2.0 and SSD
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-9380 SBC
• 1 Startup manual
• 1 Utility CD
• 1 Mini jumper pack
• 1 Audio cable
• 1 IDE 44 pin
• 1 USB 2 port cable
• 1 Parallel port cable
• 1 Keyboard/Mouse cable
• 1 26-34 pin FDD adapter
• 1 FDD Cable for Slim FDD
• 1 Flat cable 34 pins for FDD
• 1 second serial port cable
• 1 ATX power cable 20P-12P
cable
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-9380, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html (Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCM-9380 Series Rev. A1.
Part No. 2006938001
Standard SBC Functions
• CPU: Embedded Intel Pentium M (Banias/Dothan) /LV/
p/n: 9689000002
p/n: 1703100152
p/n: 1701440351
p/n: 1703100121
p/n: 1700260250
p/n: 1700060202
p/n: 9681000044
• System Memory: 1x SODIMM socket, support ECC
p/n: 1701260125
p/n: 1701340700
p/n: 1701140201
• 2nd Cache Memory: Depends on CPU type from
p/n: 1700000265
• System Chipset: Intel 855GME GMCH/ICH4 chipset
• BIOS: Award 4Mbit Flash BIOS
• Watchdog Timer: 255 levels timer interval
• Expansion Interface: MIO interface, integrated PCI
• Battery: Lithium 3V/196 mAH
• Power management: Supports power saving modes
• Enhanced IDE interface: One channels supports up to
• Optional FDD Interface: Supports one FDD
• Serial ports: Two serial RS-232 ports, COM1: RS-232,
• Parallel port: One parallel port, supports SPP/EPP/
• Keyboard/mouse connector: Supports one standard
• Audio: Support AC97 Audio stereo sound
• USB: Three USB 2.0 compliant universal serial bus
Solid State Disk
• Supports one 50-pin socket for CFC type I/II
VGA/LVDS Interface
• Chipset: Intel 855GME GMCH
• Memory Size: Optimized Shared Memory Architecture,
• Resolution:
2nd Edition
Oct. 2005.
Specifications
ULV Celeron M Processor supported at Front Side Bus
(FSB) 400MHz
on board Celeron M 600 (512K)
on board Pentium M 1.1G
socket 478(*), Ethernet
socket 478, Gigabit Ethernet
Optional:
Penitum M 745 1.8GHz
Pentium M 1.6GHz
Pentium M 738 1.4GHz
Celeron M 320 1.3GHz
*: socket 478 for Intel uFCPGA2
Double Data Rate (DDR) 128 MB to 1GB, DDR200/266/
333 DRAM
512KB to 2 MB
2.0, LPC, USB2.0, SMBus, AC97 and DVO bus.
including Normal/Standby/Suspend modes. APM 1.2,
ACPI compliant, Supports Enhanced Intel Speed Step
Technology.
two EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports UDMA 33 mode
COM2: RS-232/422/485
ECPmode
PC/AT keyboard and a PS/2 mouse
ports
support up to 64MB frame buffer using system memory
CRT display Mode: pixel resolution up to
1600 x 1200 @85-Hz and 2048 x 536 @75Hz
LVDS display mode: up to UXGA panel resolution
with frequency range from 25-MHz to 112-MHz
PCM-9380 Startup Manual
PCM-9380F-M0A1
PCM-9380F-S1A1
PCM-9380F-00A1
PCM-9380FG-00A1
1
