Operating instructions

General operation
The DLRO100E, 100X and 100H are primarily controlled by two rotary switches and a TEST button used to start and stop a test (see
section entitled, "Instrument control and indicators").
MAN AUTO
MAN AUTO
DLRO100E, 100X & 100H – 100A
Test Mode rotary switch
The Test Mode rotary switch includes an 'OFF' position; the instrument switches on by
rotating the switch clockwise from this position. Test modes provided are:
MAN
Manual
Range rotary switch
10A
Ω
50A
100A
10A 50A
DLRO100
C1 -
P1 -
MAN AUTO
OK
TEST
10A
Ω
50A
AUTO
Auto
100A
A light blue coloured section which denotes memory functions; delete
records; download records via USB or Bluetooth
(100X and 100H Only)
A spanner enabling instrument and test settings.
A custom test selection, 10 A, 50 A and 100 A pre-set test currents.
100A
C1
C2
- C2
- P2
P1
P2
10A
10A
Ω
Ω
50A
50A
100A
100A
CAT IV
600 V
Continuous
and retrieve records.
®
Save button
(100X and 100H only)
Backlight button
Navigate via Directional and
an OK buttons
OK
TEST button to start and stop
a test.
TEST
