7 Asset tagging
Asset tagging (DLRO100H models only)
7.1 PC position
Moving the rotary switch to the PC position will show
the download screen. Test switch can be MAN, AUTO or
CONTINUOUS. For Bluetooth
7.3 End download
Tagged data received successfully
DLRO100E, 100X & 100H – 100A
MAN
AUTO
®
pair as defined before here.
MAN
AUTO
7.2 Asset tag
10A
Ω
50A
100A
Instrument ready to receive tag data
10A
Ω
50A
100A
MAN
AUTO
10A
Ω
50A
100A
22
www.megger.com
