6 Remote operation

Remote operation (DLRO100H models only)
6.1 PC position
Moving the rotary switch to the PC position will show
the download screen. Test switch can be MAN, AUTO or
CONTINUOUS.
6.2 Remote control mode
Instrument under PC control showing PC then Ctrl
6.3 Test under remote control
DLRO100E, 100X & 100H – 100A
10A
Ω
50A
100A
Remote control of DLRO100 is possible on 100H models only and
is over USB but not with a Tablet or Smart phone. (PC/Laptop
only.)
Remote control mode is activated with the Range switch.
10A
Ω
50A
100A
10A
Ω
50A
100A
NOTE: Results cannot be remotely saved on the instrument. The
user can save results into a Power DB form on the PC. Remote
control can be terminated from the PC or by moving either rotary
switch. If a test is in progress the test can be terminated from the
PC or again on the instrument by moving either rotary switch or
pressing the test button.
10A
Ω
50A
100A
