Assembly / fitting
Please check that the parts are complete after unpacking the transport vehicle.
Item
1
2
3
4
5
6, 9
7
8
11
13, 14
16
17
(not illustrated)
(not illustrated)
(not illustrated)
(not illustrated)
3.2
Fitting TROLLY 70-1; 70-2; 70-3
• Loosely screw cylinder holder (11) to the base assembly (16) [(12) thread] using the M8X15
self-locking hexagonal screws (13).
• Insert one tube A (17) and B (8) through the tube guides (10) on the cylinder holder (11) into the
holes (15) on the base assembly (16) and screw on loosely using the M8X15 self-locking
hexagonal screws (14).
• Screw the wire feed carrier plate (2) using the M8X10 hexagonal screws (6) and the DV302
holder plates (5) onto the tubes already fitted. The position of the holder plates (5) (angle
section up or down) depends on the wire feed case to be transported (chap. 4.4).
• Connect the second tube A (17) to the tube B (8) already fitted and the second tube B (8) to the
tube A (17) already fitted and screwn on loosely to the base assembly (16). (Fig. 3/1).
• Tighten all loosely fastened screws.
• Screw the fitted tubes to the tube guides (10) using the M8X10 hexagonal screws (9) and
tighten.
• Affix the rubber blank (not illustrated) onto the wire feed carrier plate (2).
• Insert the press arbor socket (3) into the relevant hole in the wire feed carrier plate (2).
• Insert the press arbor (4) into the fitted socket (3).
• Screw the clamping plates (7) onto the wire feed carrier plate (2) using the star handles (1).
After assembly, check that all the screws and connections are tightly secured.
Ensure that the correct clamping plates (7) for the equipment being fitted have been used
(chap. 2.2 and chap. 4.3).
The procedure for fitting the holder plates (5) depends on the wire feed case being
transported (chap. 4.4)
Qua
Description
ntity
Star handle
4
Wire feed carrier plate
1
Press arbor socket
1
Press arbor
1
DV302 holder plate
2
M8X10 hexagonal socket screw, black galvanised
10
Standard clamping plate
2
Tube B high (TROLLY 70-1)
2
Tube B medium (TROLLY 70-2 / 70-2 DF)
Tube B high (TROLLY 70-3 / 70-3 DF)
1
Cylinder holder
M8X15 self-locking hexagongal screw
6
Base assembly, fully fitted with wheels, holding plate, cylinder base
1
Tube A high (TROLLY 70-1)
2
Tube A medium (TROLLY 70-2 / 70-2 DF)
Tube A high (TROLLY 70-3 / 70-3 DF)
Rubber blank
1
Gas cylinder securing chain
1-2
Tube guide (TROLLY 70-2 DF / 70-3 DF only)
2
Cylinder guide (TROLLY 70-2 DF / 70-3 DF only)
1
3/2
