Quick Guide:
Bio-logic AuDX PRO FLEX
®

Testing: Tympanometry

Connect the probe to the red connector and the air cable to the pump connector. From the start menu, select
the Immittance button, then select Tymp, and select Clinical. Select the test ear by pressing either the Right
or Left button. Cartoon mode will show an airplane on the screen during the tympanometry test. Connect a
second transducer to the blue connector for Contralateral Reflex testing.
Select the appropriate ear tip size and place it on the probe tip.
Insert the probe in the ear making sure that the eartip fits tightly into the ear canal.

Tympanometry test screen

The system will first check the probe fit and wait for
the pressure build up.
Note: The LED light on the probe will pulse at a steady
pace to indicate a correct fit. During the test, if the
probe tip fit is not correct, the LED light will blink at
a fast pace and an error message prompting you to
retry or cancel the test will appear on the screen.
Once a proper seal has been obtained, the test will proceed. A tympanometry test will be performed, followed
by a reflex measurement (when Clinical is chosen)
Tympanometry result
3
Quick start
®
Reflex test in progress Reflex threshold found
Otometrics - Next generation Bio-logic products
Bio-logic
Headphones or
second transducer
Second transducer
Air Pump
Overall Reflex test result
®
