Control
Bit 08="1" - 3-19 Jog Speed [RPM] determines the output
frequency.
Bit 09, Selection of ramp 1/2
Bit 09="0" - ramp 1 is active (3-40 Ramp 1 Type to
3-47 Ramp 1 S-ramp Ratio at Decel. Start).
Bit 09="1" - ramp 2 (3-50 Ramp 2 Type to 3-57 Ramp 2 S-
ramp Ratio at Decel. Start) is active.
Bit 10, Data not valid/Data valid
Tells the frequency converter whether it should use or
ignore the control word.
Bit 10="0" - the control word is ignored.
Bit 10="1" - the control word is used. This function is
relevant, because the control word is always contained in
the telegram, regardless of which type of telegram is used.
Thus, it is possible to turn off the control word, if it is not
wished to use it when updating or reading parameters.
Bit 11, Relay 01
Bit 11="0" - relay 01 not activated.
Bit 11="1" - relay 01 activated, provided control word bit
11 has been selected in 5-40 Function Relay.
Bit 12, Relay 04
Bit 12="0" - relay 04 has not been activated.
Bit 12="1" - relay 04 has been activated, provided Control
word bit 12 has been selected in 5-40 Function Relay.
Bit 13/14, Selection of set-up
Bits 13 and 14 are used to select from the 4 menu set-ups
according to Table 4.10:
The function is only possible when Multi-Set-ups is selected
in 0-10 Active Set-up.
Set-up Bit 14
1 0
2 0
3 1
4 1
Table 4.10 Selection of Set-up
NOTICE
In 8-55 Set-up Select a selection is made to define how
bit 13/14 gates with the corresponding function on the
digital inputs.
Bit 15 Reverse
Bit 15="0" - no reversing.
Bit 15="1" - reversing.
4.5.2 Status Word according to FC Profile
(STW)
The status word is used to inform the master (e.g. a PC) of
the operation mode of the slave (frequency converter).
MG37G102
Programming Guide
Refer to chapter 7 Application Examples for an example of a
status word telegram using PPO type 3.
Bit Bit=0
00 Control not ready
01 Frequency converter
not ready
02 Coasting
03 No error
04 No error
05 Reserved
06 No error
07 No warning
08 Speed reference
09 Local operation
10 Out of frequency limit
11 No operation
12 Frequency converter OK Stopped, autostart
13 Voltage OK
14 Torque OK
15 Timer OK
Table 4.11 Definition of Status Bits
Explanation of the status bits
Bit 00, Control not ready/ready
Bit 00="0" - the frequency converter has tripped.
Bit 00="1" - the frequency converter controls are ready, but
the power component is not necessarily receiving any
power supply (in case of 24 V external supply to controls).
Bit 01, frequency converter ready
Bit 13
Bit 01="0" - the frequency converter is not ready for
0
operation.
1
Bit 01="1" - the frequency converter is ready for operation,
0 but there is an active coasting command via the digital
inputs or via serial communication.
1
Bit 02, Coasting stop
Bit 02="0" - the frequency converter has released the
motor.
Bit 02="1" - the frequency converter can start the motor
when a start command is given.
Bit 03, No error/Trip
Bit 03="0" - the frequency converter is not in fault mode.
Bit 03="1" - the frequency converter is tripped, and that a
reset signal is required to re-establish operation.
Bit 04, No error/Error (no trip)
Bit 04="0" - the frequency converter is not in fault mode.
Bit 04="1" - there is a frequency converter error but no
trip.
Bit 05, Not used
Bit 05 is not used in the status word.
Bit 06, No error/triplock
Bit 06="0" - the frequency converter is not in fault mode.
Bit 06="1" - the frequency converter is tripped, and locked.
Danfoss A/S © Rev. 05/2014 All rights reserved.
Bit=1
Control ready
Frequency converter ready
Enable
Trip
Error (no trip)
-
Triplock
Warning
Speed=reference
Bus control
Frequency limit ok
In operation
Voltage exceeded
Torque exceeded
Timer exceeded
