Parameters
9-16 PCD Read Configuration
[10] Array
Option:
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1678] Analog Out X45/1 [mA]
[1679] Analog Out X45/3 [mA]
[1684] Comm. Option STW
[1687] Bus Readout Alarm/Warning
[1689] Configurable Alarm/Warning Word
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1836] Analog Input X48/2 [mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1860] Digital Input 2
9-18 Node Address
Range: Function:
126 [ 0 - Enter the station address in this parameter or
*
126 ] alternatively in the hardware switch. In order to
adjust the station address in parameter 9-18 Node
Address, the hardware switch must be set to 126
or 127 (that is, all switches set to 'on'). Otherwise
this parameter displays the actual setting of the
switch.
9-22 Telegram Selection
Option: Function:
Select a standard PROFIBUS
telegram configuration for the
frequency converter, as an
alternative to using the freely
configurable telegrams in 9-15 PCD
Write Configuration and 9-16 PCD
Read Configuration.
[1] Standard telegram 1
[101] PPO 1
[102] PPO 2
MG37G102
Programming Guide
9-22 Telegram Selection
Option:
Function: [103]
[104]
[105]
[106]
[107]
[108]
9-23 Parameters for Signals
Array [1000]
Read only
Option:
[0]
*
[15]
[302]
[303]
[312]
[341]
[342]
[351]
[352]
[380]
[381]
[411]
[412]
[413]
[414]
[416]
[417]
[553]
[558]
[590]
[593]
[595]
[597]
[615]
[625]
[653]
[663]
[673]
[683]
[748]
[890]
[891]
Danfoss A/S © Rev. 05/2014 All rights reserved.
Function:
PPO 3
PPO 4
PPO 5
PPO 6
PPO 7
PPO 8
*
None
Readout: actual setup
Minimum Reference
Maximum Reference
Catch up/slow Down Value
Ramp 1 Ramp Up Time
Ramp 1 Ramp Down Time
Ramp 2 Ramp Up Time
Ramp 2 Ramp Down Time
Jog Ramp Time
Quick Stop Ramp Time
Motor Speed Low Limit [RPM]
Motor Speed Low Limit [Hz]
Motor Speed High Limit [RPM]
Motor Speed High Limit [Hz]
Torque Limit Motor Mode
Torque Limit Generator Mode
Term. 29 High Ref./Feedb. Value
Term. 33 High Ref./Feedb. Value
Digital & Relay Bus Control
Pulse Out #27 Bus Control
Pulse Out #29 Bus Control
Pulse Out #X30/6 Bus Control
Terminal 53 High Ref./Feedb. Value
Terminal 54 High Ref./Feedb. Value
Term 42 Output Bus Ctrl
Terminal X30/8 Bus Control
Terminal X45/1 Bus Control
Terminal X45/3 Bus Control
PCD Feed Forward
Bus Jog 1 Speed
Bus Jog 2 Speed
Function:
This parameter
6
contains a list of
signals available for
selection in
parameter 9-15 PCD
Write Configuration
and
parameter 9-16 PCD
Read Configuration.
