Danfoss VLT PROFIBUS DP MCA 101 Programming Manual page 36

Parameters
8-05 End-of-Timeout Function
Option:
[0] Hold set-
up
[1] Resume
*
set-up
6 6
8-06 Reset Control Word Timeout
This parameter is active only when [0] Hold set-up has been
selected in parameter 8-05 End-of-Timeout Function.
Option:
[0] Do not reset Retains the set-up specified in
*
[1] Do reset
8-07 Diagnosis Trigger
Option:
[0] Disable
*
[1] Trigger on
alarms
[2] Trigger
alarm/warn.
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the fieldbus installed in slot A are visible in the LCP display.
For guidelines in selection of [0] Frequency converter profile and
[1] PROFIdrive profile, refer to the design guide of the related
product.
For additional guidelines in the selection of [1] PROFIdrive profile,
[5] ODVA and [7] CANopen DSP 402, see the installation guide for
the installed fieldbus.
Option:
[0]
*
[1]
[5]
[7]
34
Programming Guide
Function:
Select the action after receiving a valid control
word following a timeout. This parameter is
active only when 8-04 Control Timeout Function
is set to [7] Set-up 1, [8] Set-up 2, [9] Set-up 3 or
[10] Set-up 4.
Retains the set-up selected in 8-04 Control
Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
frequency converter resumes its original set-up.
Resumes the set-up active before the timeout.
Function:
parameter 8-04 Control Word Timeout Function,
following a control word timeout.
Returns the frequency converter to the
original set-up following a control word
timeout. The frequency converter performs
the reset and then immediately reverts to the
[0] Do not reset setting.
Function:
Enables and controls the frequency converter
diagnosis function.
Extended diagnosis data are not sent even if
they appear in the frequency converter.
Extended diagnosis data are sent when one
or more alarms appear.
Extended diagnosis data are sent if one or
more alarms/warnings appear.
Function:
FC profile
PROFIdrive profile
ODVA
CANopen DSP 402
Danfoss A/S © Rev. 05/2014 All rights reserved.
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the fieldbus installed in slot A are visible in the LCP display.
For guidelines in selection of [0] Frequency converter profile and
[1] PROFIdrive profile, refer to the design guide of the related
product.
For additional guidelines in the selection of [1] PROFIdrive profile,
[5] ODVA and [7] CANopen DSP 402, see the installation guide for
the installed fieldbus.
Option:
[8] MCO
8-50 Coasting Select
Option: Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
[0] Digital Activates start command via a digital input.
input
[1] Bus Activates start command via the serial
communication port or fieldbus option.
[2] Logic Activates start command via the fieldbus/serial
AND communication port, AND additionally via one
of the digital inputs.
[3] Logic OR Activates start command via the fieldbus/serial
*
communication port OR via one of the digital
inputs.
8-51 Quick Stop Select
Select control of the Quick Stop function via the terminals
(digital input) and/or via the bus.
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
Only selection [0] Digital input is available
when 1-10 Motor Construction is set to [1]
PM non-salient SPM.
[0] Digital Activates start command via a digital input.
input
[1] Bus Activates start command via the serial communi-
cation port or fieldbus option.
[2] Logic Activates start command via the fieldbus/serial
AND communication port, AND additionally via one of
the digital inputs.
Function:
Function:
MG37G102
