- Page 1 Read the operating instructions prior to commissioning Operating instructions Lava stone grill Unit Type of energy Unit type Model Argentina 1 Floor-standing unit OPGGSGARG… Argentina 2 HLGGSGARG… Countertop unit SLGGSGARG… Weld-in ESGGSGARG... 1001064120ABBE-- en-GB...
- Page 2 Operating and display elements Image: Argentina 1 lava stone grill a Inspection port for Flame c Inspection port for Pilot burner monitoring monitoring b Burner control knob d Piezo pilot ignitor button Image: Argentina 2 lava stone grill a Piezo pilot ignitor button d Burner control knob b Heat zone identification e Inspection port for Pilot burner...
- Page 3 Fax +49 5331 89-280 Internet www.mkn.eu Copyright All rights to text, graphics and pictures in this documentation are held by MKN Maschinenfabrik Kurt Neubauer GmbH & Co. KG. Distribution or duplication is only permitted with the prior written consent of MKN.
-
Page 4: Table Of Contents
Directory of contents 1 Introduction ................. 7 1.1 About this manual ................ 7 1.1.1 Explanation of signs .................. 8 1.2 Intended use .................. 9 1.3 Warranty .................... 9 2 Safety information ............ 10 3 Rules of conduct when the smell of gas is detected .. 13 4 Description of the unit ............. 14 4.1 Overview of the unit ... - Page 5 Directory of contents 7.2 Nameplate .................. 25 8 Carrying out maintenance .......... 26 9 Disposing of the unit in an environmentally responsible manner ................. 27 10 Manufacturer's declaration .......... 28 Operating instructions...
-
Page 6: Directory Of Contents
Directory of contents Operating instructions... -
Page 7: 1 Introduction
Introduction 1 Introduction 1.1 About this manual The operating instructions are part of the unit and contain information: • On safe operation, • On cleaning and care, • On remedies in case of faults. Be aware of the following notes and adhere to them: •... -
Page 8: Explanation Of Signs
Introduction 1.1.1 Explanation of signs DANGER Imminent threat of danger Failure to comply will lead to death or very severe injuries. WARNING Possible threat of danger Failure to comply can lead to death or very severe injuries. CAUTION Dangerous situation Failure to comply can lead to slight or moderately severe injuries. -
Page 9: Intended Use
Introduction 1.2 Intended use This unit is intended to be used solely for commercial purposes, particularly in commercial kitchens. This unit may only be used with suitable accessories and for the cooking of food. It is forbidden to use the unit for purposes, which include the following: •... -
Page 10: 2 Safety Information
Safety information 2 Safety information The unit complies with applicable safety standards. Residual risks associated with operation or risks resulting from incorrect operation cannot be ruled out and are mentioned specifically in the safety instructions and warnings. The operator must be familiar with regional regulations and observe them. - Page 11 Safety information Risk of fire from overheating • Observe the unit during operation. • Check the water level of the receiver tank regularly. Risk of fire from objects • Do not obstruct the exhaust gas duct. Firefighting • In the event of a fire, use the gas shut-off valve to isolate the unit from the gas supply.
- Page 12 Safety information • Do not place any plastic or aluminium materials on the grilling stones. • Do not put pots, pans or aluminium trays on the grates or grilling stones. • Do not grill directly on the grilling stones. • Do not operate the unit without grilling stones or grates.
-
Page 13: 3 Rules Of Conduct When The Smell Of Gas Is Detected
Rules of conduct when the smell of gas is detected 3 Rules of conduct when the smell of gas is detected DANGER Risk of asphyxiation and explosion from escaping gas Follow the rules of conduct when the smell of gas is detected. •... -
Page 14: 4 Description Of The Unit
Description of the unit 4 Description of the unit The unit is intended for universal use in commercial kitchens for cooking food. Suitable for cooking with contact heat, for frying fast-fry food and for grilling. 4.1 Overview of the unit 4.1.1 Floor-standing unit Image: Argentina 2 gas lava stone grill a Grilling surface with grate... -
Page 15: Countertop Unit
Description of the unit 4.1.2 Countertop unit Image: Argentina 2 gas lava stone grill a Grilling surface with grate f Collection container b Lava stone grate g Collection plate c Front grate holder h Lava stone d Nameplate and gas type i Rear grate holder supplemental label e Control panel... -
Page 16: Function Of The Operating And Display Elements
Description of the unit 4.2 Function of the operating and display elements Operating/display element Symbol Designation Function Burner control knob Switch off gas supply Ignition Gas supply for pilot burner is released, the burner is switched off Output Set the burner output Piezo pilot ignitor button Ignite pilot burner Flame monitoring inspection... -
Page 17: 5 Operating The Unit
Operating the unit 5 Operating the unit CAUTION Risk of burns from hot surfaces • Protect arms and hands by wearing suitable protective gloves. 5.1 Tips on using In order to use the unit to its optimum and avoid heat loss: •... -
Page 18: Switching Off
Operating the unit 5.2.2 Switching off During operation the Burner control knob is safeguarded against unintentional shifting to the " " setting. Press the Burner control knob and turn it to the " " setting. Gas supply is stopped. The burner is switched off. The pilot burner is switched off. -
Page 19: Loading In The Water
Operating the unit 5.3.2 Loading in the water Water prevents the dripping grill residue from igniting and burning. When loading the water, observe the fill quantity and check it regularly during operation. Image: Loading in the water 1. Remove the collection container from the unit. 2. -
Page 20: Placing The Lava Stones In Position
Operating the unit 5.3.4 Placing the lava stones in position Image: Placing the lava stones in position Requirements Unit switched off and cooled down Grate has cooled down 1. Remove the grate from the unit. 2. Place one layer of lava stones in position. Maintain a small distance between the lava stones. -
Page 21: Pauses And End Of Use
Operating the unit 5.5 Pauses and end of use Switch off the unit during pauses and at end of use. 5.5.1 Brief pauses When restarting the unit after pauses, first check the function of the pilot burner in order to prevent a flash fire. 1. -
Page 22: 6 Cleaning And Caring For The Unit
Cleaning and caring for the unit 6 Cleaning and caring for the unit CAUTION Risk of burns from hot surfaces • Allow surfaces to cool prior to cleaning. ATTENTION Risk of physical damage from improper cleaning • Do not clean the unit with a high-pressure cleaner or water jet. -
Page 23: Cleaning The Housing
Cleaning and caring for the unit 6.3 Cleaning the housing ATTENTION Risk of physical damage from improper cleaning • Do not clean the housing with highly abrasive or chemically aggressive cleaning agents. • Do not clean the housing with highly abrasive sponges. Requirement Unit switched off and cooled down Clean the housing with warm water and commercially available washing-up liquid. -
Page 24: Performing A Visual Inspection
Cleaning and caring for the unit 6.7 Performing a visual inspection ATTENTION Risk of physical damage from improper inspection • Inspect in accordance with the inspection intervals. • Have inspections performed by a capable user. • In the event of damage or signs of wear, contact customer service immediately and stop using the unit. -
Page 25: 7 Troubleshooting
Troubleshooting 7 Troubleshooting DANGER Risk of fatal injury from escaping gas • Gas installation work on the gas system and unit may only be performed by an expert approved by the gas utility. The applicable regional regulations of the gas utility must be observed. -
Page 26: 8 Carrying Out Maintenance
Carrying out maintenance 8 Carrying out maintenance The unit is maintenance-free, there are no maintenance requirements. Operating instructions... -
Page 27: Disposing Of The Unit In An Environmentally Responsible Manner
Disposing of the unit in an environmentally responsible manner 9 Disposing of the unit in an environmentally responsible manner Do not dispose of unit or the unit's components together with non- recyclable waste. If the unit is disposed of together with non- recyclable waste or treated improperly, toxic substances contained in the unit can damage health and pollute the environment. -
Page 28: 10 Manufacturer's Declaration
Manufacturer's declaration 10 Manufacturer's declaration EC Declaration of Conformity Manufacturer MKN Maschinenfabrik Kurt Neubauer GmbH & Co. KG • Halberstädter Straße 2a • 38300 Wolfenbüttel, Germany We hereby declare, that the following product: Description of the unit Unit for cooking food in commercial applications Designation / Unit type Gas lava stone grill / XXGGSG... - Page 32 www.mkn.eu...
