Measured value
Current Iac L1
Current Iac L2
Current Iac L3
Current Iac mean
Current Idc
Current Idc1...
Current Idc12
Current Ierr gnd
Current Ierr_ac
Current Ierr_dc
Current Ierr_eff
Chained voltage L1 – L2
Chained voltage L1 – L3
Chained voltage L2 – L3
Temp. power unit 1
Cosphi
String 1 ... string 16
Insolation
Insolation energy day
Ambient temp. 1
Ambient temp. 1
Cell temp.
Energy counter A day
Energy counter A total
Energy counter A year
Energy counter B day
Energy counter B total
Energy counter B year
Click on the Next button to continue the wizard.
Description
AC output current, phase 1
AC output current, phase 2
AC output current, phase 3
DC proportion in mains current
DC input current
Fehlerstrom gegen Erde
DC input current tracker 1 ... tracker 12
Leakage current to ground
AC proportion in leakage current to ground
DC proportion in leakage current to ground
Effective value of AC proportion in leakage current to
ground
Voltage between the L1 and L2 outside conductors
Voltage between the L1 and L3 outside conductors
Voltage between the L2 and L3 outside conductors
Temperature of the power unit 1
Power factor
String current 1 ... string current 16 (MaxConnect+)
Solar irradiation (MaxMeteo)
Irradiation energy of the current day (MaxMeteo)
Ambient temperature 1 (MaxMeteo)
Ambient temperature 2 (MaxMeteo)
Solar cell temperature (MaxMeteo)
Daily yield current counter 1 (MaxCount)
Total yield current counter 1 (MaxCount)
Annual yield current counter 1 (MaxCount)
Daily yield current counter 2 (MaxCount)
Total yield current counter 2 (MaxCount)
Annual yield current counter 2 (MaxCount)
Unit
A
A
mA
A
A
mA
mA
mA
mA
V
V
V
°C
A
W / m2
kWh / m2
°C
°C
°C
kWh
kWh
kWh
kWh
kWh
kWh
kWh
kWh
