3�3
3�3�1
The LEDs indicate the operational status of the device. As soon as the device is supplied
with power, the LEDs are flashing until the internal functions are checked; the ON LED
then lights continuously.
ON
STATUS
WLAN
3�3�2
The device features a two-line LCD display that shows important information and the
status of the plant.
As soon as the device is supplied with power, the MaxWeb XPN is switched on automati-
cally. During start-up, the LCD display shows the message "booting". Once the message
"OK" appears in the LCD display, the MaxWeb XPN is ready for operation.
In this menu, you can change the basic settings, such as the selected language, execute
basic functions and check operating functions using the navigation keys.
12

Displays

Status indicators

ON
cont. light
STATUS
off
off
cont. light

LCD display

Note
Via the LCD display, only basic settings can be made. The full scope of func-
tions of the MaxWeb XPN can only be used via the web browser.
ON
When the device is ready for operation
STATUS
During normal operation
WLAN is inactive, no WLAN connection
When the device is connected to the WLAN
