Advantech ECU-P1761 Startup Manual

ECU-P1761
4-ch Isolated Digital Input, 4-ch Isolated Relay Output with IRIG-B Board

Packing List

Before installation, make sure that you have the ECU-P1761
suit which includes the card and panel as below.
If anything is missing or damaged, contact your distributor or
sales representative immediately.
Diagram

Notes

For more information on this and other Advantech products, please
visit our websites at:
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com.tw/eservice
This manual is for ECU-P1761
Part No: 2003P17600
1 Startup Manual
The ECU-P1761 supports the following specifications:
• Connector: 120-pin connector for UNO-4673A/4683/ECU-
• BUS Interface: PCI
• Dimensions: 5.3'' x 6.0'' (136 x 150 mm)
• Power Requirements: 5V @ 150mA (typical); 3.3V @
• Certification: CE, FCC, IEC-61850-3 Compliant

Digital Input

• Channels：
• Connector：
• Input Type：
• Input Voltage：
• Response time：
• Isolation Voltage：

Relay Output

• Channels
• Connector
• Output Type
• Relay Output Voltage
• Max. Switching Voltage
• Relay Output Current:
• Operate/Release Time：
• Isolation Voltage：

IRIG-B

• IRIG Interface
• Precision
• Resolution of time
• Message Syntax
The ECU-P1761 is an expansion card for ECU-4784 which
has 2 expansion slots and UNO-4673A/4683 which has 3
expansion slots. ECU-P1761 can be plugged into any of the
slots. Follow these steps to integrate into ECU-4784/UNO-
4673A/4683.
1. Select one of the slots: unscrew the two screws on the
2. Plug the ECU-P1761 into the selected slot of ECU-4784/
1st Edition
June 2016

Specifications

4784
60mA (typical)

Installation

blank panel of the slot then remove the blanking plate.
UNO-4673A/4683 carefully and fix it by the two screws
on the panel.
4
Terminal Block
Wet Contact (Sink)
Logic 0: 0~10V; Logic
1: 30~48V
1 ms
2,500 VDC
4
Terminal Block
Relay; 1 Form C
250 VAC/VDC
400 VAC
25°C 3A,70°C, 1A
Max. 8ms
2,500 VDC
BNC
1ms
1s
YYYYQQQHHMMSS
(year, day, hour,
minute& second)
