ECU-P1706
250 kS/s 16-bit Simultaneous 8-ch Analog Input PCI-104 Card
Packing List
Before you begin installing your module, please make
sure that the following materials have been shipped:
ƒ ECU-P1706 card
ƒ Energy Series Driver and Utility DISC
ƒ Quick Start User Manual
ƒ 1 x Front Panel (for ECU-P1706)
ƒ 2 x 18 pin plug-in-blocks
ƒ 6 x M3 bolts
ƒ 1x ROHS list
ƒ 1 x Warranty card
If any of these items are missing/damaged, contact
your distributor or sales representative immediately.
User Manual
For more detailed information on this product, please
refer to the ECU-P1706 user manual on the CD-ROM
(PDF format). CD:\ ECU-P Cards\ECU-P1706\User's
Manual.
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com.tw/eservice
This manual is for ECU-P1706.
Part No: 2003I70601
2nd Edition
December 2013
Overview
The ECU-P1706 is an advanced high-performance
multifunction card based on the Universal PCI-104
bus.The maximum sampling rate of ECU-P1706 is
up to 250 kS/s with 8 A/D converters simultaneously
sampling on each channel, With a large FIFO of
8K Sample.The ECU-P1706 has two 32-bit Time/
counter channels so that it can provide specific
functions for different application requirements.
Declaration of Conformity
FCC Class A
This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 ofthe FCC Rules. These limits
are designed to provide reason-able protection
against harmful interference when theequipment
is operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with theinstruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause interference in which case the user is
required to correct interference at his own expense.
CE
This product has passed the CE test for environmental
spec-ifications when shielded cables are used
for external wiring.We recommend the use of
shielded cables. This kind of cable is available from
Advantech. Please contact your local representative.
ECU-P1706 Startup Manual 1
