Conquest
Monitor:
Control Electronics
Module:
Remote Keypad:
Remote Keypad
Receiver:
Sensor Keypad:
Monitor Keypad:
Grid Mat:
Selector:
Slide:
Slide Show:
Color Bar:
3D View:
PCD - Power
Cable Detector:
PCD Image:
PCD Profile:
PCD Amplitude:
PCD Frequency:
DynaQ:
the display panel mounted inside the display unit.
module mounted inside the display unit which holds electronic control circuits,
distributes signals and houses the removable flash memory.
the wireless keypad which enables operation of Conquest from a distance.
the infrared receiver that detects commands from the remote keypad.
keypad mounted on the sensor.
keypad mounted below the display monitor in the display unit.
plastic or paper sheet with grid lines pre-marked to enable grid scans. Often the
name is shortened to just grid or mat.
the highlight box that appears around the current selected menu item.
name of an image in the Conquest "Help" section.
term applied to the process of automatically displaying Conquest "Help" slides
with a timed delay.
the bar of colors which display the colour palette on the Conquest "Color" menu
items. Colors to the left represent strong, negative signals and colors to the right
indicate strong, positive signals. Colors in the middle represent weak signals.
the term used in Conquest where depth slices and cross-sections are displayed
simultaneously to show a 3D display on flat display.
device within the Conquest sensor head for measuring the magnetic field inten-
sity produced by power lines carrying electric current at the power line frequency.
plan view display of PCD amplitude.
plot of PCD amplitude variation along a line.
intensity of magnetic field detected.
power cable detector fundamental frequency selectable by user (e.g. 60 Hz in
North America, 50 Hz in Europe/Australia)
a technology that adjusts Conquest data quality as the sensor head movement
speed varies.
Appendix E: Conquest Glossary
E-3
