Odometer Wheel Calibration - Sensors & Software Conquest Series Manual

8-Helpful Hints
4. Operating in a temperature very different from the temperature that the System Test
was last performed in.
To perform the system test, follow the simple, on-screen instructions.
If constantly prompted to run the System Test, it may be necessary to turn the IEP feature off and
collect the data without it (see Image Enhancement Processing).
8.9

Odometer Wheel Calibration

The odometer wheel calibration is done under Wheel Cal in Tools. The odometer wheel should
be periodically calibrated, perhaps once a week or once a month. It should also be re-calibrated
if you are collecting data on a different surface than usual, for example, on a textured floor rather
than smooth concrete. Calibrating on long lines ensures the highest accuracy.
40
Conquest
