Typical System Equipment Room Floor Plans

General

The equipment room floor plan must be provided by the FSO for firm
quote price lists. For all other quotes, the equipment room floor plans
must be provided by the PSC. Factors that influence the design are:
Size and layout of the equipment room
Number of equipment cabinets
Location of AC receptacles
Size of the switch.

Typical Floor Plans

Figure 3-8 is a typical floor plan for a 2-carrier System 75 or a 2-cabinet
System 75 XE. Figure 3-9 is a typical floor plan for a 5-carrier System 75
or a 3- or 4-cabinet System 75 XE. The maximum capacity for a 2-carrier
cabinet is 200 stations and the maximum capacity for a 5-carrier cabinet
is 800 stations.
