Signet 2839-1V to 2842-1V PVDF Conductivity Electrodes
*3-2840.090-1*
3-2840.090-1
Rev. C 04/17
2839: 0.01 cm
-1
2840: 0.1 cm
2841: 1.0 cm
2842: 10.0 cm
•
English
•
Deutsch
•
Français
•
Español
•
Italiano
中文
•
Table of Contents
-1
Warranty Information ............................................................................ 2
Product Registration ............................................................................. 2
Safety Information................................................................................. 2
Specifi cations........................................................................................ 3
Dimensions ........................................................................................... 3
Cell Constant Selection ........................................................................ 4
Custom Cell Certifi cate ......................................................................... 4
Installation............................................................................................. 4
In-Line Installation................................................................................. 4
Submersible Installation........................................................................ 5
Integral Installation................................................................................ 5
General Wiring ...................................................................................... 6
ProcessPro Wiring ................................................................................ 6
SmartPro Wiring ................................................................................... 6
Maintenance ......................................................................................... 7
2842 Insulator ....................................................................................... 7
Ordering Information ............................................................................. 8
-1
-1
Operating Instructions
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GF Signet 2839
Summary of Contents for GF Signet 2839
-
Page 1: Table Of Contents
English Signet 2839-1V to 2842-1V PVDF Conductivity Electrodes *3-2840.090-1* 3-2840.090-1 Rev. C 04/17 Operating Instructions Table of Contents 2839: 0.01 cm 2840: 0.1 cm Warranty Information ................2 Product Registration ................2 Safety Information................. 2 Specifi cations..................3 Dimensions ................... 3 Cell Constant Selection ................ -
Page 2: Warranty Information
Do not exceed maximum temperature/pressure include a fully completed Service Form and goods must be specifi cations. returned to your local GF Sales offi ce or distributor. Wear safety goggles or faceshield during installation/ Product returned without a Service Form may not be service. -
Page 3: Specifi Cations
Specifi cations Dimensions General 2839: 0.01 cm Instrument Compatibility ..2850, 8850-3, 8860, 9900 Cable 4.6 m (15 ft) std., 3 conductor with shield, 22 AWG, max length 30 m (100 ft). For resistivity measurements above 10 MΩ or below 20 °C, maximum cable length is 7.6 m (25 ft). Process Connection -1V ........ -
Page 4: Cell Constant Selection
Cell Constant Selection The nominal process value should be near the center of the range. Signet Conductivity/Resistivity Electrode Ranges Ranges below are for use with Signet Conductivity Instruments: 2842 10.0 cm 0.010 to 100 μS (10 kΩ to 100 MΩ) •... -
Page 5: Submersible Installation
Submersible Installation Feed cable into watertight conduit. Apply thread sealant to the electrode before threading conduit onto electrode. Avoid twisting the cable. Secure cable with conduit or cable gland. For additional defense against possible accumulation of condensation at the back seal area of the electrode, fi... -
Page 6: General Wiring
General Wiring • Do not route electrode cable in conduit containing AC power wiring. Electrical noise may interfere with electrode signal. • Routing electrode cable in grounded metal conduit will help prevent electrical noise and mechanical damage. • Seal cable entry points to prevent moisture damage. •... -
Page 7: Maintenance
Maintenance Conductivity electrodes require little maintenance except for periodic cleaning in installations where contaminants are present. • Keep metal surfaces clean and free of coatings. 2842 Insulator Replacement Insulator, 2842 electrode only • 2842 electrodes have a removable insulator so the internal cavity can be cleaned. •... -
Page 8: Ordering Information
Ordering Information PVDF Conductivity Electrodes Mfr. Part No. Code Description 3-2839-1V 159 001 810 Cell 0.01, 4.6 m (15 ft) cable, PVDF NPT threaded fi tting 3-2839-1VD 159 001 811 Cell 0.01, 4.6 m (15 ft) cable, PVDF ISO threaded fi tting 3-2840-1V 159 001 812 Cell 0.1, 4.6 m (15 ft) cable, PVDF NPT threaded fi...
