Figure 1. Tunneling interface for the SCG
•
NOTE: Refer to

Core Network Protocols

Each UE is mapped to one single core network protocol type. A maximum of 64
core gateways is supported, which translates to supporting 32 GGSNs and 64 GRE
core gateways including L2oGRE in any combination.
This section covers:
• L2oGRE
• L2oGRE with TTG PDG Profile with 802.1x Authentication
• Bridge Mode - (0-2 tags)
• GTP Tunnel with GGSN (GTPv1)
• GTP Tunnel with PGW (GTPv2)
• PMIPv6 Tunnelling
