16" 36V 8Ah Ultra Compact Foldable Electric
Bike
FS36V16EBKA
Quick Start Guide
Table of Contents
Safety & Warnings .................................................................................................................................................... 2
Overview ...................................................................................................................................................................... 5
Assembly ..................................................................................................................................................................... 5
Operation ..................................................................................................................................................................... 8
Cleaning & Care ........................................................................................................................................................12
Troubleshooting ...................................................................................................................................................... 16
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fortis FS36V16EBKA
Summary of Contents for Fortis FS36V16EBKA
- Page 1 16” 36V 8Ah Ultra Compact Foldable Electric Bike FS36V16EBKA Quick Start Guide Table of Contents Safety & Warnings ..............................2 Overview ..................................5 Assembly ..................................5 Operation ..................................8 Cleaning & Care ................................12 Troubleshooting ..............................16...
-
Page 2: Safety & Warnings
Safety & Warnings Cycling can be a hazardous activity even under the best circumstances. Giving proper maintenance to your electric bike is your responsibility as it helps to reduce the risk of injury. This manual contains many warnings and cautions concerning the consequences of failure to maintain or inspect your electric bike. - Page 3 Know the Law Cyclists are required to follow the traffic rules. Additionally, some communities regulate the use of motorised bicycles regarding minimum age requirements and necessary equipment. Check with your local police department for specific details. Correct Frame Size When selecting a new bicycle, the frame size is a very important safety consideration. Most full-sized bicycles come in a range of frame sizes.
- Page 4 Bicycle safety helmet should always be worn while riding your bicycle. The correct helmet should: Be comfortable • Be lightweight • Have good ventilation • Fit correctly • Cover your forehead •...
-
Page 5: Overview
Overview Folding Electric Bicycle Assembly Pedal Installation The pair of pedals will have “R” and “L” markings (picture 1), “R” for right, “L” for left. Tighten the pedals onto the unit by turning them clockwise (R) or anti-clockwise (L). (Picture 2) Picture 1 Picture 2... -
Page 6: Front Wheel
Front Wheel Make sure that the brakes are loose enough to allow the wheel to pass through the brake pads easily. 2. Place wheel into fork dropouts. 3. Install retaining washers with the raised lip pointed towards the fork and insert them into the small hole of the fork blade. - Page 7 touching the centre of the pedal. If this is not the case, your saddle height needs to be adjusted. B: Saddle Tilt Adjustment Most people prefer a horizontal saddle, but some riders prefer the saddle nose tilted slightly up or down. You can adjust the saddle by loosening the saddle quick release and then tilt the saddle to the desired position and retighten the saddle quick release.
-
Page 8: Operation
Operation Please read and understand these instructions completely before operating your Electric Bike to prevent serious injury to yourself and others and to prevent damage to the bike. Important notices: Always recharge the battery immediately after each use. Failing to do, may •... - Page 9 6. The load standard weight is 75kg (including the rider weight), please do not overload with more wright. 7. A rear brake system has been installed to the Electric Bike, it will automatically cut off power supply to the motor and slow down when you pull the brake and then the rear brake in the back tyre stops the Electric Bike.
- Page 10 Picture 5 Power Indicator When the throttle or sensor is engaged (Powering the motor) and the bicycle is in motion, the LED on the battery gauge (on the throttle or separate unit) indicate instantaneous line voltage as measured at the battery terminals and not the available energy in the battery pack. The line voltage will wing out on a dead stop or going up a steep hill, the motor will be under a high load and may show a reduced number of LED indications or show the “Yellow”...
- Page 11 Pedal Assist System The bike has an electric pedal assisted driving system. The driving assisted system consists of a driving unit, a battery, a controller and various electronic components (harness wires, sensors and switches). It is important to know that when the assistant system is turned on, the driving unit engages to provide power only while you are pedalling.
-
Page 12: Cleaning & Care
Cleaning & Care Inspection and Maintenance For your safety and enjoyment and to ensure a long life of your Electric Bike, inspect and maintain your Electric Bike regularly. Use the table below for guidance. It is very important that you check certain systems and components before each ride. The proper condition and function of these systems is critically important for your safety. -
Page 13: Flat Tire
condensation, as this could cause shorting or corrosion. The recommended storage temperature for Li-ion batteries is between 0-25 °C. • Avoid exposing the battery to extreme heat (40°C or higher) for long periods of • time. Service & Maintenance Schedule Some service and maintenance should be performed by the owner and require no special tools or knowledge beyond what is presented in this manual. -
Page 14: Basic Maintenance
Carefully check the outside and inside of the tire for the cause of the puncture and remove the cause if it is still there. If the tire is cut, line the inside of the tire in the area of the cut with something handy - tape, a spare patch, a piece of inner tube, whatever will keep the cut from pinching the inner tube. - Page 15 Check the wiring and connectors periodically to ensure there is no damage and the connectors have good continuity. Store your bicycle under shelter. Avoid leaving it in the rain or being exposed to corrosive materials. Riding on the beach or in coastal areas exposes your bicycle to salt which is very corrosive. Wash your bicycle frequently and wipe or spray all unpainted parts with an anti-rust treatment.
-
Page 16: Troubleshooting
Troubleshooting Problem Possible cause Remedy Slipping chain Excessively worn/chipped chain Replace chain ring, sprockets ring or freewheel sprocket teeth and chain. chain worn. Replace chain. Stretched Stiff link in chain. Lubricate or replace link. Non-compatible chain/chain Seek advice at a bicycle shop. ring/freewheel. - Page 17 possible frame realignment Frequent punctures Inner tube becomes old or faulty. Replace inner tube. Tire tread/casing worn. Replace tire. Tire unsuited to rim. Replace with correct tire. Tire not checked after previous Remove sharp object embedded puncture. in tire. Correct tire pressure. Tire pressure is too low.
- Page 18 Indicator light on Outlet has no power. Check outlet for power. charger does not Faulty charger. Replace charger. illuminate when charger is plugged into the outlet Charger (Lithium) Damaged wire connection Inspect wire. indicator light flashes between charger port and battery. Replace batteries.
