2. Lokaset R – Operation
1 5 4
Lokaset R is designed for use as a tank full alarm for septic tanks.
The principle of operation is that when the probe comes into contact
with liquid, the transmitter transmits a signal to the Lokaset R central
unit. The signal is sent every 10 minutes and the alarm is activated by
two consecutive notes from the probe. The relay will de-energize in
case of an alarm.
The central unit (1) signals the alarm with a buzzer sound and an
alarm indicator light (2). The buzzer is silenced by the alarm reset
button (3). The alarm mode can be deactivated by emptying the
tank. The probe should be installed in the tank at the height of the
liquid alarm level.
The central unit is plugged to the mains (230 V). When the power is
connected, the green power light (4) and the radio signal indicator
(5) are on. The transmitter is battery-powered. The battery is supplied
with the device. In normal use, the battery life is at least 10 years. The
3 2
central unit signals an alarm when the transmitter is not powered or
the battery needs to be replaced.
The Lokaset R probe (SET/LV) is not suitable for measuring explosive
or corrosive liquids.
LOKASET R 5
| Installation and Operation Instructions | D18067Ae
