7. Lokaset R – Technical Specifi cations
Central Unit
Type/model Lokaset R Receiver
Manufacturer Labkotec Oy, Myllyhaantie 6,
33960 Pirkkala, Finland
Supply voltage 230 VAC, 50/60 Hz, 1 VA
Operation method Wireless receiver, 433 MHz
Relay output De-energised on alarm, potential-free
switching contacts (μ). Max. connection
values: 250 V / 4 A / 100 VA
Dimensions: hxwxd 35 x 130 x 80 mm
Installation and Class II, Indoor use only
operation class
Operation Green, blue and red indicator light, buzzer
Approvals R&TTE approval,
CE Marking
Transmitter
Type/model Lokaset R Transmitter
Manufacturer Labkotec Oy, Myllyhaantie 6,
33960 Pirkkala, Finland
Supply voltage 3 V battery, CR 123A
Operation method Wireless transmitter, 433 MHz
Dimensions: h x Ø 75 x 95 mm
Operating radius 150 m, max. transmission range 650 m
Installation and Class III, indoor and outdoor use,
operation class ambient temperature -30 ... +60°C
Protection class IP 67
Approvals R&TTE approval,
CE Marking
Probe
Type/model SET/LV
Operation method Conductivity-operated
