Chapter 8 – Mounting the Device
Mounting the Device
The device ships with a mounting bracket.
You will need
Mounting bracket
MTCAP
Four #6 screws, with anchors (not provided)
Screwdriver
Drill
Determining Location for the MTCAP
Follow these guidelines for best performance:
The LoRa antenna is omnidirectional, but for best results, mount the device so the LoRa antenna is in a
vertical position as shown in the following image.
Place the MTCAP as high as possible, such as near the top of a wall.
Select a location central to all devices to be connected to this MTCAP.
Avoid obstructions.
Important:
Thick walls and reflective surfaces, such as metal, weaken the signal between the MTCAP and other
devices.
®
Conduit
AP MTCAP-L4E1 User Guide for Europe
Mounting Bracket
MOUNTING THE DEVICE
27
