SETTING UP HARDWARE

Chapter 5 – Setting Up Hardware

If your device has a SIM slot, you'll need a micro SIM card from your network provider.

To install the SIM card:

With the contact side facing down, align the notched edge as shown on the following image and slide the

SIM card completely into the SIM holder.

To remove the SIM card, push the SIM card in. The device ejects the SIM card.

To cable the device:

Connect the Ethernet cable to the Ethernet port on the device and to your computer.

Connect the power supply to the MTCAP's power jack and plug it into an electrical outlet. When the

operating system is fully loaded, the STATUS LED blinks.

Once your device is cabled, follow the Getting Started chapter for your device:

For models ending with -001L , go to

For models ending with -001A, go to

Getting Started with mLinux

Getting Started with AEP
