Startup Options

Whenever the control is started for the first time or after a manual reset, it will initiate its operation
with the Startup Menu. Moreover, the Startup menu can be accessed by selecting it from the
operation menu. An option must be selected in each screen in the Startup Menu to move to the next
level.
Standard
Options: english, metric
: MENU/<System Startup>/Standard
SET
Due to the large variety of inputs available to connect to the SPC-Elite, this option helps in narrowing
down the sensor type options.
• I f English is selected, sensor types in ˚F (Fahrenheit), PSI (Pounds/Square inch), Hg (Inches of
Mercury for Vacuum) will be available.
• I f Metric is selected, sensor types in ˚C (Celsius), MPa (Million Pascal), mm (Millimeter of
Mercury for Vacuum) will be available.
• % RH (Relative Humidity) will be available in both options.
Sensor Type
Options: temp.250˚F/121˚C, temp.900˚F/480˚C, Pres. 30PSi/0.25mPa, Pres. 100PSi/0.60mPa,
Pres. 200PSi/1.0mPa, Pres. 300PSi/1.6mPa, Vac. 30Hg/760mm, and relative Humidity %rH
default: temp.250˚F/121˚C
: MENU/<System Startup>/Standard/Sensor Type
SET
• T he Sensor Type available options depend on the Standard option selected from the previous menu.
Any temperature value above the sensor range will display SHORT. Any temperature value below the sensor range will display
OPEN. Any pressure, vacuum or humidity value above the sensor range will display OPEN. Any pressure, vacuum or humidity
Control Mode
Options: Heat-Breakonrise, Cool-makeonrise
: MENU/<System Startup>/Standard/Sensor Type/Control Mode
SET
The SPC-Elite can operate in either mode.
• I n Heat-Break-On-Rise mode the relay will energize when the sensor value is below the set point.
• I n Cool-Make-On-Rise mode the relay will de-energize when the sensor value is below the set
point.
Sensor Fault
Options: all off, all on
: MENU/<System Startup>/..../Sensor Fault
SET
The Sensor Fault will determine the operating status of the relay when a sensor reads Short or Open.
On sensor fault the Set Point will indicate FAULT TGT=ON or OFF to indicate the condition of
the output and the Sensor will read SYSTEM=OPEN or SHORT to indicate the condition of the
sensor.
Manually Resetting the Control to Defaults
To Reset the SPC-Elite control to its original factory defaults, power down the control. Hold down
the SET and DOWN buttons while powering the control back up until the Loading Default Values
screen appears. The Display will direct you to the Startup menu after the defaults are loaded to pro-
gram the control as if for the first time.
When resetting the control to original factory defaults all control
settings will be over written and will no longer exist.
value above the sensor range will display SHORT.
ALERT
4
default: english
ALERT
default: Heat-Breakonrise
default: all on
STANDARD:
English
Metric
SENSOR TYPE:
Temp. 250 F
Temp. 900 F
Pres. 30psi
Pres. 100psi
Pres. 200psi
Pres. 300psi
Vacuum 30in
Humidity %RH
SENSOR TYPE:
Temp. 121 C
Temp. 480 C
Pres. 0.250MPapsi
Pres. 0.600MPapsi
Pres. 1.000MPapsi
Pres. 1.600MPapsi
Vacuum 760mm
Humidity %RH
CONTROL MODE:
Heat-BreakOnRise
Cool-MakeOnRise
SET
SENSOR FAULT:
Output On
Output Off
SET
SYSTEM= OPEN
FAULT TGT= ON
SET
Loading Default SET
Values...
SET
