Specifications

Voltage Input:
. . . . . . . 120 VAC 60 Hz(2 Black wires) /24VAC 60 Hz (24VAC terminals) (Only One Power Source)
Power Consumption:
Operating Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20°F/-7°C to 120°F/49°C
Operating Humidity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20% to 80%
Dimensions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4"W x 4"H x 2½"
Shipping Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pound
Output: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 S.P.D.T (White+Red = N.O.), (Blue+Red = N.C.)
Output Relay Ratings: . . . . . . . . . . . . . . . . . . . . . . . . 1 Amp inductive, 6Amp resistive at 120 VAC 60 Hz
Operating Modes: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Heat (Break on Rise) or Cool (Make on Rise)
Sensor Fault Operating Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Output On or Output Off
Temperature Ranges: . . . . . . . . . . from -30˚F (-34˚C) to 250˚F (121˚C) or from 220˚F (104˚C) to 900˚F (480˚C)
Pressure Ranges: . . . . PSI (0-30PSI, 0-100 PSI, 0-200PSI, 0-300PSI) or MPa (0.25MPa, 0.60MPa, 1MPa, 1.6MPa)
Vacuum Range:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30Hg or 760mm
Humidity Range: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0% to 100% RH
Display: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Alphanumeric (2 rows x 16 char. each)
LED: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Middle LED representing the Output relay
Buttons:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 (Set, Up, Down)
Enable/Disable: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Terminals EXT+, EXT-
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 VA Max
