1. Verify all components included with the extender set are present before installation.
2. Turn off power and disconnect the audio/video equipment by following the manufacturer's
instructions.
3. Connect Category 6 or greater twisted pair cable with RJ45 connectors between the
INT-HDX100-RXWP and a compatible Intelix HDBaseT transmitter. TIA/EIA-568B straight-through wiring
connections must be used with all HDBaseT extenders.
4. Connect an HDMI cable and any desired IR, Ethernet and RS232 connections between the display
and the INT-HDX100-RXWP.
5. Connect an HDMI cable and any desired IR, Ethernet and RS232 connections between the source
and a compatible Intelix HDBaseT transmitter.
6. Connect a power supply to the compatible Intelix HDBaseT transmitter. and lock the power supply
to the power connector by twisting the locking collar clockwise.
7. Power on attached audio/video devices.
Passing IR Signals:
The INT-HDX100-RXWP is capable of passing IR signals between 30 and 50 KHz. To
prevent damage to any of the electronics, the extender should be powered off while
inserting or removing any IR components. Inserting an IR transmitter into the IR IN
port may damage the IR circuit for that extender.
Connectivity Instructions
INT-HDX100-RXWP Quick Guide
5
