Do not block the air ventilation openings. Only mount the equipment per Intelix’s instructions. » Use only with the cart, stand, table, or rack specified by Intelix or sold with the equipment. When/if a » cart is used, use caution when moving the cart/equipment combination to avoid injury from tip-over.
INT-HDX100-RXWP Owners Manual Table of Contents Product Overview ��������������������������������������������������������������������������������������������������������������������������������������� Product Contents ���������������������������������������������������������������������������������������������������������������������������������������� Receiver View ��������������������������������������������������������������������������������������������������������������������������������������������� Front and Back Panel ������������������������������������������������������������������������������������������������������������������������������������ Installation Instructions ������������������������������������������������������������������������������������������������������������������������������ Quick Start ���������������������������������������������������������������������������������������������������������������������������������������������������� Connecting a Video Source ��������������������������������������������������������������������������������������������������������������������������� HDMI Input (Transmitter not included) ....................Connecting a Display �������������������������������������������������������������������������������������������������������������������������������������...
Category cable. The INT-HDX100-RXWP supports 1080p video signal up to 100m and 4K signals up to 4K@60Hz / 4:2:0 / 8 bit color up to 70m. The INT-HDX100-RXWP supports CEC pass through and is HDCP 2.2 compliant. 48V PoH built in allows the receiver to be powered from a compatible Intelix transmitter.
INT-HDX100-RXWP Owners Manual Receiver View Front and Back Panel FRONT BACK 1. DIAGNOSTIC LED’S POWER (RED) - Solid when device is powered ON LINK (GREEN) - Solid when successful link between transmitter and receiver is established; off or blinking indicates a physical link error HDCP (GREEN) - Solid when HDMI signal is encrypted;...
HDMI Output (Receiver) Connect a display to the HDMI output on the INT-HDX100-RXWP labeled HDMI OUT using an HDMI cable that is less than or equal to 5 meters total length for 1080p signals and 1.5 meters for 4K@60 signals. It is recommended to keep the HDBaseT receiver near the display input as it is not recommended that an active HDMI cable be used on the HDMI output on the HDBaseT receiver.
INT-HDX100-RXWP Owners Manual HDBaseT Connection Connect one end of a Category cable to the INT-HDX100-RXWP receiver labeled HDBT IN, then connect the other end of the Category cable to a compatible HDBaseT Intelix transmitter labeled HDBT OUT Twisted Pair Wiring...
The INT-HDX100-RXWP is capable of transmitting a bi-direction IR signals through the HDBaseT circuit. An IR emitter (Intelix DIGIB-EMT sold seperately) can be connected to the IR OUT on the back of the wall plate to transmit IR signals from a compatible Intelix HDBaseT transmitter. An IR receiver (Intelix DIGIB-EYE sold seperately) can also be connected to the IR IN on the back of the wall plate to transmit IR signals to a compatible Intelix HDBaseT transmitter.
INT-HDX100-RXWP Owners Manual Application Diagram IR REMOTE 1 MEDIA PLAYER CONTROL SYSTEM Intelix INT-HDX100-TX (NOT INCLUDED) HDMI CATx AUDIO RS232 up to 100m / 330’ IR REMOTE 2 FRONT BACK PROJECTOR...
Page 10
Thank you for your purchase. For Technical Support please call our toll free number at 800-530-8998 or email us at supportlibav@libav.com www.libav.com Intelix is a brand of:...
