1 - Introduction
Model Part #
iDynamo 6 with
21087019
USB-C Plug
Table 1-2 - iDynamo 6 Accessories
Accessory
Battery Pack
Universal Mounting Bracket
USB-C to USB Type A Cable
iDynamo 6| Secure Card Reader Authenticator | Installation and Operation Manual
Connections
USB-C plug for:
• Host communication
• Handheld power input from host
• Charging power output to host
USB-C receptacle for:
• Charging power input
• Contactless reader power input
• Host communication / operating
power input if plug disabled
Battery pack contacts for:
• Charging power output to battery pack
• Handheld power input from battery
for contactless reader
Part #
1000005550 Must be ordered separately.
1000005552 Included with device. Spares available for order.
1000005076 Included with device. Spares available for order.
Page 15 of 41 (D998200321-20)
Host / Solution Design
Types
Direct mount to iOS and
Android devices with USB-C
connector.
Notes
