Installing side panel blanks on a 42U IT rack

The HPE ARCS 42U Air Rack Installation Kit is for 42U racks and includes the following side panel
blanks.
Item
1
2
3
4
5
For more information on the HPE ARCS 42U Air Rack Installation Kit contents, see Accessory and
option kit contents.
To install the rear extension blanks:
1. Place the blank against the IT rack, and line up the screw holes.
2. Install four screws to hold the blank in place.
26 Configuration
Description
4 small side panel blanks for the rear extension
4 large side panel blanks for the rear extension
24 rack side panel blanks
2 "Panel D" side panel blanks for the front
extension
10 "Panel B" side panel blanks for the front
extension
